STARTECH.COM

POE + MIDSPAN INJECTOR GIGABIT 4 PORT POWER OVER ETHERNET INJECTOR

SKU: ZM2204VPN: POEINJ4G

POE + MIDSPAN INJECTOR GIGABIT 4 PORT POWER OVER ETHERNET INJECTOR

Key Features

  • Easily connect, power, and operate up to four Gigabit PoE-powered devices (PD)
  • Delivers full power to each port - up to 30.8 watts (802.3at) or 15.4 watts (802.3af) to each connected device
  • Flexible setup, with a desktop-sized, or wall-mountable metal housing
  • Plug-and-play setup and operation
  • Automatically detects the powered device to provide the appropriate level of power output
  • Circuit protection prevents power interference between each port
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

Deliver power and data to four Power over Ethernet devices using this wall-mountable PoE+ midspan hub. This Gigabit midspan PoE+ injector is a cost-effective alternative to upgrading your existing network switch to a PoE-capable model.It supplies up to 30 Watts output to each port, so you can easily power and access up to four high-power PoE-compliant devices - such as IP cameras - using standard Ethernet cable.More power, with less cost and hassleThis versatile midspan PoE+ injector is suited for almost all PoE device classes, including wireless access points, as well as IP phones and cameras. The high-power PoE+ injector offers 120W total power distribution and delivers full power - up to 30.8W - from each port. Now, you can easily scale and power your PoE+ devices across long distances, even in remote locations where a typical power outlet is unavailable.Plus, the cost-effective Power over Ethernet+ injector lets you connect your PoE-powered devices (PDs) to a non-PoE-capable switch, avoiding the expense and aggravation of upgrading your existing switch to a PoE-enabled model.Easy to set up in mixed environmentsThis injector is the perfect solution for a variety of environments. It features a wall-mountable rugged metal casing, but is palm-sized making it perfect for desktop placement too.With plug-and-play operation, you can enjoy fast and hassle-free setup without disrupting your workflow.Convenient, protected connectionsNot sure which class your PoE devices are The Gigabit midspan PoE+ injector automatically detects the power requirements of your PoE PDs, and delivers the appropriate level of power without damaging your devices.With integrated circuit protection between each port, your devices are also protected from power interference.The POEINJ4G is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Tech Specs

POE + MIDSPAN INJECTOR GIGABIT 4 PORT POWER OVER ETHERNET INJECTOR specifications
Width2.8"
Height1"
Length3.8"
Brand NameStarTech.com
Mount TypeWall Mountable
Form FactorExternal
Input Ports4
Color FamilyBlack
ManufacturerStarTech.com
Output Ports4
Product Name4 Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af
Product TypePoE Injector
Show all 33 specs
Compatibility<ul><li>IP Cameras</li><li>IP Phones</li><li>Wireless Access Points</li></ul>
Input Voltage120 V AC
Product ColorBlack
WEEE Statementhttps://media.startech.com/cms/pdfs/poeinj4g_weee.pdf
Package Contents<ul> <li>4 Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af</li> <li>1 x Universal Power Adapter </li> <li>3 x Power Cords (NA/UK/EU) </li> <li>1 x Instruction Manual</li> </ul>
Country of OriginTaiwan
Maximum Frequency60 Hz
Packaged Quantity1 Each
REACH free of SVHCYes
Weight (Approximate)7.80 oz
REACH Declaration URLhttps://media.startech.com/cms/pdfs/poeinj4g_rohs.pdf
Maximum Output Current2.31 A
Maximum Output Voltage52 V DC
EU RoHS Declaration URLhttps://media.startech.com/cms/pdfs/poeinj4g_rohs.pdf
Environmental ComplianceRestriction of Hazardous Substances (RoHS) 2
Environmentally FriendlyYes
Manufacturer Part NumberPOEINJ4G
Certifications & Standards<ul><li>CE</li><li>FCC</li><li>IEEE 802.3af PoE</li><li>IEEE 802.3at PoE+</li><li>IEEE 802.3 10BASE-T</li><li>IEEE 802.3u 100BASE-TX</li><li>IEEE 802.3ab 1000BASE-T</li></ul>
Environmental CertificationEU RoHS
Manufacturer Website Addresshttp://www.startech.com
End of Life Manual AvailabilityYes
