8PORT RACKMOUNT KVM SWITCH 1U USB/PS2 ON SCREEN DISPLAY
8PORT RACKMOUNT KVM SWITCH 1U USB/PS2 ON SCREEN DISPLAY
Key Features
- NetController 8-Port, 1U rackmount KVM switch
- Control 8 computers via a single VGA monitor and USB or PS/2 keyboard/mouse
- Control up to 248 computers by daisychaining up to 15 additional B042-Series KVM switches
- P780-Series USB/PS2 combo KVM cables kits allow you to connect either USB or PS/2 computers, without the need to purchase separate cables or adapters
- Compatible with all major operating systems
Adding to inquiry lets you bundle multiple products into a single quote request.
Overview
Tripp Lite's NetController 8-Port, 1U rackmount KVM Switch is an affordable, highly-flexible enterprise class KVM Switch, which allows the user to connect either USB or PS/2 keyboards and mice. In addition, P780-Series USB/PS2 combo KVM cable kits allow you to connect either USB or PS/2 computers, without the need to purchase separate cables or adapters. Control up to 8 directly connected computers, or expand the number of connected computers to up to 248 by daisychaining up to 15 additional B042-Series KVM switches. Switch between connected computers via the On-Screen Display (OSD), pushbuttons, or keyboard hotkey commands. Other features include: password protection, auto-scanning, auto-logout, firmware upgrade and video support up to 2048 x 1536 (QXGA). Mounts easily in a standard 19" rack/cabinet and includes all necessary mounting hardware. Compatible with all major operating systems. Constructed of heavy-duty steel housing. 3 year limited warranty.
Tech Specs
| Depth | 6.5" |
|---|---|
| Width | 16.1" |
| Height | 1.8" |
| PS/2 Port | Yes |
| Brand Name | Tripp Lite series |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Graphic Mode | QXGA |
| Manufacturer | Eaton Corporation |
| Product Name | KVM Switch |
| Product Type | KVM Switchbox |
| Input Voltage | 9 V DC |
Show all 22 specsShow fewer
| Product Model | B042-008 |
|---|---|
| Package Contents | <ul><li>KVM Switch</li><li>External Power Supply</li><li>Rackmount Hardware</li><li>4 ft. HD15 to DB9 Firmware Upgrade Cable</li><li>8-in Daisy-Chain Cable - HD15M/HD15F</li><li>Daisy Chain Terminator - HD15M</li><li>CD with owner's manual and quick start guide</li><li>Quick start guide</li></ul> |
| Country of Origin | China |
| Number of PS/2 Ports | 1 |
| Daisy Chain Supported | Yes |
| Environmentally Friendly | Yes |
| Manufacturer Part Number | B042-008 |
| Maximum Video Resolution | 2048 x 1536 |
| Manufacturer Website Address | http://www.eaton.com |
| Number of Computers Supported | 8 |
Datasheets & Resources
