STARTECH.COM

USB HARD DRIVE DOCKING STATION 2.5 3.5 SATA HDD SSD USB 3.0 DOCK

SKU: TW6113VPN: SDOCKU33BV

USB HARD DRIVE DOCKING STATION 2.5 3.5 SATA HDD SSD USB 3.0 DOCK

Key Features

  • Supports 2.5in and 3.5in form factor SATA hard drives (HDD) and solid state drives (SSD)
  • UASP Support (Attached SCSI Protocol Specification Revision 1.0)
  • Compatible with USB 3.0/2.0/1.1 (5 Gbps / 480 Mbps / 1.5 Mbps)
  • Compatible with SATA revision I/II/III (1.5/3.0/6.0 Gbps) drives
  • Plug-and-Play and Hot-Swap compatible
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

The SDOCKU33BV UASP-enabled USB 3.0 docking station makes it easy for you to connect and swap 2.5in or 3.5in SATA III hard drives (HDD) and solid state drives (SSD) through an available USB port. The dock performs up to 70% faster than conventional USB 3.0 when paired with a UASP-enabled host controller to utilize the full potential of your SATA III hard drives. With support for large capacity SATA I/II/III drives (tested up to 4TB), and 2.5in or 3.5in drives this HDD/SSD docking station is compatible with virtually any SATA drive, and greatly increases the storage/backup capabilities of your computer. Extend the value of this hard drive docking station further with the addition of our SATA to IDE Hard Drive Adapter (SAT2IDEADP), allowing easy insertion of any 2.5 or 3.5in IDE hard drive into a SATA hard drive dock. To ensure compatibility with your computer system, the SDOCKU33BV supports all of the leading operating systems, including: Microsoft Windows® (8/7/Vista/XP/Server 2008/Server 2003), Apple® OSX (10.9/10.8/10.7/10.6), Linux, and Google Chrome OS™. The SDOCKU33BV is backed by a 2-year StarTech.com warranty and free lifetime technical support. Improved Performance with UASP UASP is supported in Windows 8, Mac OSX (10.8 or above), and Linux. In testing, UASP performs with a 70% faster read speed and 40% faster write speed over traditional USB 3.0 at peak performance. At the same peak in testing UASP also shows an 80% reduction in required processor resources. Testing results were obtained using an Intel® Ivy Bridge system, a UASP-enabled StarTech.com Enclosure, and a SATA III solid state drive.

Tech Specs

USB HARD DRIVE DOCKING STATION 2.5 3.5 SATA HDD SSD USB 3.0 DOCK specifications
Depth5.5"
Width3.6"
Height2"
Brand NameStarTech.com
Cooling FanNo
Form FactorExternal
Color FamilyBlack
ManufacturerStarTech.com
Power SourceAC Adapter
Product NameUSB 3.0 SATA III Hard Drive Docking Station SSD / HDD with UASP
Product TypeDrive Dock
UASP SupportYes
Show all 32 specs
Wireless LANNo
Input Voltage220 V AC
Product ColorBlack
Host InterfaceUSB 3.0 Type B
Drive InterfaceSATA/600
Package Contents<ul> <li>USB 3.0 SATA III Hard Drive Docking Station SSD / HDD with UASP</li> <li>1 x USB 3.0 Cable</li> <li>1 x Universal Power Adapter</li> <li>1 x Instruction Manual</li> </ul>
Country of OriginChina
Packaged Quantity1 Each
Platform SupportedPC
Weight (Approximate)11.20 oz
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
Environmentally FriendlyYes
Manufacturer Part NumberSDOCKU33BV
Number of 2.5"/3.5" Bays1
Manufacturer Website Addresshttp://www.startech.com
Number of Total Expansion Bays1
Number of Hard Drives InstalledNo
Number of Hard Drives Supported1
Number of Solid State Drive InstalledNo
Number of Solid State Drive Supported1
