STARTECH.COM

HARD DRIVE BAY MOBILE RACK DUAL 2.5IN SATA HDD SSD HOT SWAP

SKU: U45138VPN: HSB220SAT25B

HARD DRIVE BAY MOBILE RACK DUAL 2.5IN SATA HDD SSD HOT SWAP

Key Features

  • Holds up to two SATA drives in a single 3.5" bay
  • Trayless design: drives are not mounted into separate trays/enclosures
  • Includes a plastic protective film for the bottom side of hard drive
  • Aluminum construction
  • 50,000+ insertion rating
  • Power/Activity LED for each drive
  • Support for SATA revision I/II/III (1.5/3.0/6.0 Gbps)
  • Supports 2.5" form factor SATA hard drives (HDD) and solid state drives (SSD)
  • Plug-and-Play and Hot-Swap compatible
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

This 3.5in SATA hard drive hot-swap bay allows you to install two 2.5in SATA hard drives (HDD) or solid state drives (SSD) in an available/unused 3.5in floppy drive bay. Featuring a convenient "no mounting required /easy eject" feature (like a tape cartridge or floppy disk), the hard drive hot swap bay doesn't require that the drives be installed in a tray - making it the ideal solution for quick and easy drive removals and insertions as part of a system building process, or integration into rackmount systems or industrial environments. To maximize performance and utilize the full speed potential of your SATA III hard drives, this HDD Backplane supports SATA III for transfer speeds up to 6 Gbps when paired with a compatible controller. Also a perfect addition for operating system image deployment and any task that requires being able to quickly access large volumes of data on the fly, the hot swap bay provides everything you need to expedite important projects while maintaining a reliable storage solution. With support for SATA HDD speeds up to 6.0 Gbps, this backplane is fully compatible with RAID installations to ensure maximum performance and versatility for enhanced storage applications.

Tech Specs

HARD DRIVE BAY MOBILE RACK DUAL 2.5IN SATA HDD SSD HOT SWAP specifications
Depth5.3"
Width4"
Height0.9"
Brand NameStarTech.com
Form FactorInternal
Color FamilyBlack
ManufacturerStarTech.com
Product Name2 Drive 2.5in Trayless Hot Swap SATA Mobile Rack Backplane
Product TypeDrive Enclosure
Wireless LANNo
Product ColorBlack
Host InterfaceSerial ATA/600
Show all 32 specs
Controller TypeSerial ATA
Drive InterfaceSATA/600
Package Contents<ul> <li>2 Drive 2.5in Trayless Hot Swap SATA Mobile Rack Backplane</li> <li>2 x Lp4 To SATA And LED Adapter Cable </li> <li>1 x 15-Pin SATA Power And LED Y Cable </li> <li>2 x 7-Pin SATA Data Cable </li> <li>2 x Hard Drive Protector Film </li> <li>1 x Screw Kit </li> <li>1 x Instruction Manual </li> </ul>
Product MaterialAluminum
Country of OriginTaiwan
Packaged Quantity1 Each
Number of 2.5" Bays2
Weight (Approximate)10.10 oz
Additional Information<ul><li>Quickly and easily install or remove HDD/SSD without having to open the chassis with the innovative trayless design</li><li>Aluminum construction and 50,000+ insertion rating ensures longevity from both the HDD/SSD and bay</li><li>Backed by a StarTech.com 2-year warranty and free lifetime technical support</li></ul>
Environmental ComplianceWaste Electrical and Electronic Equipment Directive (WEEE)
Environmentally FriendlyYes
Manufacturer Part NumberHSB220SAT25B
Compatible Drive Bay Width3.5"
Environmental CertificationEU RoHS
Manufacturer Website Addresshttp://www.startech.com
Number of Total Expansion Bays2
Number of Hard Drives InstalledNo
Number of Hard Drives Supported2
Number of Solid State Drive InstalledNo
Number of Solid State Drive Supported2
