LEGRAND AV - C2G
THUNDERBOLT 3 DOCK 8K 180W TAA
SKU: SG7088VPN: C2G54536
THUNDERBOLT 3 DOCK 8K 180W TAA
Key Features
- Wired connectivity technology provides a high-powered and dependable connection
- Charging capability provides a quicker, worry-free charging experience
- Thunderbolt 3 host interface Offers a more refined structure and safer to use connectivity
- Docking Station provides a convenient and easy charging solution for your notebook with maximum usability
- 5 GB/s maximum data transfer rate for dependable access and retrieval of data and information with added usability
- LED Power Indicator feature for better reliance and usability
- Lets you conveniently connect to the gigabit ethernet Ethernet technology to offer maximum productivity
- Power Supply power source type for your docking station better reliance and maximum energy dependability
- 6 USB ports offers a more refined structure and safer to use connectivity
- 1 Network (RJ-45) Ports eliminates the need of installing additional electrical wiring
Request a Quote on This Product
Adding to inquiry lets you bundle multiple products into a single quote request.
Overview
The Thunderbolt 3 USB-C 11-in-1 8K UHD Docking Station with DisplayPort, Ethernet, USB, SD Card Reader, 3.5mm Audio, and Power Delivery connects to Thunderbolt 3 enabled laptops and features 180W of power, making it ideal for commercial workstation laptops that need more video outputs, more connected peripherals, and the ability to transfer data while staying charged.
This Thunderbolt 3 USB-C 8K UHD Docking Station offers 180W to support connected devices, such as keyboards, mice, portable hard drives, and other peripherals, all while supporting up to 85W of power delivery to charge and power a commercial workstation laptop when using the USB-C power adapter that is included with the laptop. The maximum power capacity depends on how much power the connected adapter can supply. The right amount of power is necessary to keep the laptop battery charged, for all connected devices to function, and for the dock to provide that connectivity. This docking station includes a 180W power supply.
Supporting two displays with resolutions up to 4K (3840 x 2160) at 60Hz for high definition images and video makes this docking station a perfect desktop solution, whether you are in the office or working from home. Professional users can also connect to a single DisplayPort display through the DisplayPort port and support resolutions up to 8K (7680 x 4320) at 30Hz. The USB-A ports support SuperSpeed USB 5Gbps data transfers # allowing up to 32GB of data to be downloaded in under a minute. The Thunderbolt 3 ports support data transfers up to 40Gbps # 8x faster than SuperSpeed USB 5Gbps. The Ethernet port allows for reliable internet connectivity with file transfer speeds up to 1000Mbps. Access multimedia content quickly with the SD 4.0 card reader that supports SD, SDHC, and SDXC up to 128GB. Optimize performance by connecting displays designed for 4K 60Hz signals, USB devices designed for 5Gbps transfer speeds, and Thunderbolt 3 enabled devices.
PORTS
1x 8K DisplayPort: Connect to an 8K display via the DisplayPort port.1x Thunderbolt 3 Video and Data: Connect to a 4K display and transfer data up to 40Gbps from a storage device.
1x Thunderbolt 3 Power and Data: Transfer data up to 40Gbps from a storage device and power a commercial laptop with up to 85W power delivery.
2x USB-C: Connect storage devices and transfer data up to 10Gbps through the USB-C port.
3x USB-A: Connect storage devices and transfer data up to 5Gbps through the USB-A ports.
1x USB-A with BC 1.2: Connect storage device and transfer data up to 5Gbps through the USB-A port. This port supports BC 1.2 for enhanced mobile device charging.
Gigabit Ethernet: Connect to local network for network and internet access.
Combo Audio Jack: Connect headphones, speakers, and headphone/microphone sets for audio output and input.
SD 4.0 Card Reader: Insert SD memory card for data transfer.
Tech Specs
| Depth | 3.50" |
|---|---|
| Width | 7.80" |
| Height | 1" |
| Features | Power Delivery Pass-through |
| Brand Name | C2G |
| USB Type-A | Yes |
| USB Type-C | Yes |
| DisplayPort | Yes |
| Thunderbolt | Yes |
| Color Family | Black |
| Manufacturer | Legrand Group |
| Product Name | C2G Thunderbolt™ 3 USB-C 11-in-1 8K UHD Docking Station with DP, Ethernet, USB |
Show all 51 specsShow fewer
| Product Type | Docking Station |
|---|---|
| Compatibility | Thunderbolt 3 Enabled Laptops |
| Product Color | Black |
| TAA Compliant | Yes |
| Host Interface | Thunderbolt 3 |
| Network (RJ-45) | Yes |
| Device Supported | Hard Drive |
| Limited Warranty | 5 Year |
| Package Contents | <ul><li> Docking Station</li><li> 180W Power Supply</li></ul> |
| Country of Origin | Taiwan |
| Power Source Type | Power Supply |
| USB Type-C Detail | 2 x USB-C |
| Memory Card Reader | Yes |
| USB Power Delivery | 85W |
| Charging Capability | Yes |
| DisplayPort Version | 1.4 |
| Ethernet Technology | Gigabit Ethernet |
| Memory Card Supported | SDXC |
| Number of RJ-45 Ports | 1 |
| Screen Mode Supported | 4K @ 60Hz |
| Supported Resolutions | 7680 x 4320 |
| Number of DisplayPorts | 1 |
| Connectivity Technology | Wired |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Kensington Security Slot | Yes |
| Manufacturer Part Number | C2G54536 |
| Total Number of USB Ports | 6 |
| Maximum Data Transfer Rate | 5 GB/s |
| Number of USB Type-A Ports | 4 |
| Number of USB Type-C Ports | 2 |
| Operating System Supported | Windows |
| Thunderbolt Ports Quantity | 2 |
| Manufacturer Website Address | http://www.legrand.us |
| Maximum Power Supply Wattage | 180 W |
| Number of Displays Supported | 2 |
| Number of Thunderbolt 3 Ports | 2 |
| Number of USB 3.1 Type-C Ports | 2 |
| Headphone/Microphone Combo Port | Yes |
| Number of Network (RJ-45) Ports | 1 |
