9PX 3000VA 2700W 208V ONLINE DBL-CNV LI-ION UPS W/ C13 C19
9PX 3000VA 2700W 208V ONLINE DBL-CNV LI-ION UPS W/ C13 C19
Key Features
- Keeps equipment running during outages to allow time for file saves and safe shutdown
- Improved lithium-ion batteries have service life up to 10 years set it and forget it!
- Provides 80% to 120% more runtime at full load than equivalent lead-acid UPS systems
- Interactive LCD interface keeps you updated on critical load information in real time
- Optional expanded battery modules allow extended runtime to keep equipment powered
Adding to inquiry lets you bundle multiple products into a single quote request.
Overview
3kVA/2.4kW/208V Long-Term Battery Backup for IT Installations and Edge Networks
This 9PX rack-mount online double-conversion UPS system provides reliable, low-maintenance battery backup and AC power protection against blackouts, brownouts, surges and line noise that can damage valuable IT equipment or destroy data. Ideal for locations that are difficult to access or infrequently maintained, the 9PX3000GRT-L is an efficient "set it and forget it" solution. It's ideal power management for education, commercial, financial or healthcare networking components, including Cisco switches and servers.
Reliable, Expandable Battery Backup Keeps You Operational Through Power Outages
The hot-swappable maintenance-free lithium-ion battery modules have a service life of 8 to 10 years. They allow you to work through short power failures and give you enough time to safely save files and shut down your system in case of a prolonged blackout. Exclusive ABM technology increases battery life by 50 percent and closely monitors battery health to provide advanced notice when batteries need replacing. These lithium iron phosphate (LFP) batteries provide 80 to 120 percent more runtime at full load than equivalent lead-acid UPS systems while weighing up to 40 percent less, reducing the overall UPS weight.
Supports External Batteries for Scalable Extended Runtime
For mission-critical applications demanding continuous uptime, the UPS supports the connection of up to four expanded battery modules (9PXEBM72RT-L, sold separately) for hours of extended runtime.
Optional Gigabit Network Interface Offers 24/7 Remote Access
The Network-M3 network card (sold separately or as a network card bundle) enables full remote configuration and management, including load shedding, reboots of connected equipment and safe shutdowns. UPS firmware can also be flashed remotely through the Network-M3 without dropping the load, so you don't have to plan for downtime. The card meets both UL 2900-1 and IEC 62443-4-2 standards for cybersecurity, which were developed to address the vulnerability of connected devices to known malware/exploits and to protect business from these risks. The optional Environmental Monitoring Probe Gen 2 (EMPDT1H1C2, sold separately) provides a variety of environmental monitoring capabilities, including temperature and humidity conditions.
Tech Specs
| Depth | 23.8" |
|---|---|
| Width | 17.3" |
| Height | 3.4" |
| Brand Name | Eaton |
| Form Factor | Rack/Tower |
| Rack Height | 2U |
| Serial Port | Yes |
| Color Family | Dual Color |
| Manufacturer | Eaton Corporation |
| Product Name | 9PX UPS |
| Product Type | Double Conversion Online UPS |
| Hot Swappable | Yes |
Show all 36 specsShow fewer
| Input Voltage | 230 V AC |
|---|---|
| Product Color | Black |
| Waveform Type | True Sine Wave |
| Product Family | 9PX |
| Product Series | 9PX |
| Sound Emission | 47 dB |
| Input Frequency | 60 Hz |
| Network (RJ-45) | Yes |
| Receptacle Type | IEC 60320 C13 |
| Package Contents | <ul> <li>9PX UPS</li> <li>Quick Start Guide</li> <li>Safety Instructions</li> <li>USB Communciation Cable</li> <li>RS-232 Serial Communication Cable</li> <li>4-post Rail for 19-inch Enclosures</li> <li>Software Leaflet</li> <li>2 x Pedestals for Tower Poition</li> </ul> |
| Application/Usage | IT |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Country of Origin | Philippines |
| Receptacle Detail | 8 x IEC 60320 C13 |
| Status Indicators | Grpahical Display |
| Load Capacity (VA) | 3000 VA |
| Network Management | Relay-MS Card |
| Plug/Connector Type | NEMA L6-20P |
| Replaceable Battery | Yes |
| Load Capacity (Watt) | 2400 W |
| Weight (Approximate) | 50.27 lb |
| Manufacturer Part Number | 9PX3000GRT-L |
| USB (HID Compliant) Port | Yes |
| Manufacturer Website Address | http://www.eaton.com |
Datasheets & Resources
Related Products
More in UPS from EATON and similar brands

CABLE ADAPTER FOR 9PX G1 AND 9P UPS AND EXTENDED BATTERY 180V
ADAPTER CABLE TO CONNECT 9PX G1 EBM TO 9PX G2 UPS (180V)

5S 550VA TOWER 120V
More from EATON
Other products available from this brand

UPS WALL-MOUNT KIT FOR SELECT 2U 5PX G2 AND 9PX UPS/EBMS
