ATEN TECHNOLOGIES

2PORT USB 3.0 4K DUAL DISPLAY DP KVMP SWITCH

SKU: 5NL255VPN: CS1942DP

2PORT USB 3.0 4K DUAL DISPLAY DP KVMP SWITCH

2PORT USB 3.0 4K DUAL DISPLAY DP KVMP SWITCH Key Features

  • One USB keyboard and mouse controls two DisplayPort computers and share two USB peripherals
  • Supports Quad Display by connecting two Dual Display KVM switches
  • Supports superior video quality - Up to 4K (4096 x 2160 / 3840 x 2160 @ 60 Hz)
  • Computer Selection via front panel, hotkeys, mouse, and RS-232 commands
  • 2- Port USB 3.1 Gen 1 hub with SuperSpeed 5 Gbps data transfer rates
  • Supports DisplayPort Dual-Mode technology (DP++)*
  • Supports MST (Multi-Stream Transport)
  • Supports Console keyboard emulation / bypass feature
  • Supports Console mouse emulation / bypass feature
  • Independent switching of KVM, USB, and Audio
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

2PORT USB 3.0 4K DUAL DISPLAY DP KVMP SWITCH Overview

The ATEN CS1942DP desktop KVM switch helps organize your desktop. Especially when managing a multimedia workstation at a large organization, CS1942DP provides you with instant access to two or four computers, all through a single USB keyboard, USB mouse and two DisplayPort monitors.

Advanced video support provides a better-defined DisplayPort connection with video resolutions up to 4K (4096 x 2160 / 3840 x 2160 @ 60 Hz). Incorporating dual display capability, you are allowed to enjoy a wider screen and easily switch between two or four DisplayPort systems. In addition, featuring a built-in USB 3.1 Gen 1 hub, the CS1942DP delivers unprecedented data transfer rates up to 5 Gbps, allowing you to maximize multimedia operations.

Engineered to meet the ever-increasing demand for dual display, ultra-fast data transmission rates, and lossless 4K video resolution, the CS1942DP is specifically designed for where multitasking is needed such as design, financial trading, and video post production.

2PORT USB 3.0 4K DUAL DISPLAY DP KVMP SWITCH Tech Specs

2PORT USB 3.0 4K DUAL DISPLAY DP KVMP SWITCH specifications
USBYes
Depth13.2"
Width6.2"
Height1.7"
Brand NameATEN
DisplayPortYes
Form FactorRack-mountable
ManufacturerATEN Technology, Inc
Product Name2-Port USB 3.0 4K DisplayPort Dual Display KVMP Switch
Product TypeKVM Switchbox
Input Voltage12 V DC
Product ModelCS1942DP
Show all 28 specs
Network (RJ-45)Yes
Package Contents<ul> <li>2-Port USB 3.0 4K DisplayPort Dual Display KVMP Switch</li> <li>4 x DisplayPort 1.2 Cables</li> <li>2 x USB 3.0 Cables</li> <li>4 x Audio Cables</li> <li>1 x Power Adapter</li> <li>1 x User Instructions</li> </ul>
Country of OriginTaiwan
Packaged Quantity1
Input Voltage Range12V DC
Number of USB Ports6
Weight (Approximate)3.40 lb
Number of DisplayPorts6
Environmental ComplianceWaste Electrical and Electronic Equipment Directive (WEEE)
Environmentally FriendlyYes
Manufacturer Part NumberCS1942DP
Maximum Video Resolution4096 x 2160
Manufacturer Website Addresshttp://www.aten.com/us/en/
Number of Computers Supported2
Number of Local Users Supported1
Number of Network (RJ-45) Ports1
