ATEN TECHNOLOGIES
2PORT UHD 4K DP PORT KVM WITH 2 CABLES
SKU: 3E8113VPN: CS782DP
2PORT UHD 4K DP PORT KVM WITH 2 CABLES
Key Features
- One DisplayPort video console controls two USB computers
- Fully DisplayPort 1.2 Compliant
- Computer selection via remote port selector, hotkeys, and USB mouse
- Superior video quality - 4K UHD (3840 × 2160 @ 60 Hz) and 4K DCI (4096 x 2160 @ 60 Hz)
- Multiplatform support - Windows, Mac, Sun, Linux
- HDCP Compliant
- Supports MST (Multi-Stream Transport), enabling multiple monitors to be used via a single DisplayPort connector
- Supports DisplayPort Dual - Mode (DP++) for directly outputting single-link HDMI and / or DVI signals via an externally powered DisplayPort-to-HDMI/DVI DP++ adapter
- Compatible with widescreen LCD monitors
- Power on detection - if either of the computers is powered off, the CS782DP will automatically switch to the other computer
Request a Quote on This Product
Adding to inquiry lets you bundle multiple products into a single quote request.
Overview
With the ever-growing demand for higher video quality and the evolution of DisplayPort technology, 4K-enabled computers and displays are now widely adopted in visually-intensive and commercial applications. Offering up to 4K resolution, the ATEN CS782DP is at home amongst these demanding scenarios and technological advancements.
The ATEN CS782DP 2-Port USB DisplayPort KVM Switch features 4K video resolution and allows users to access two 4K-enabled computers from a single USB keyboard, USB mouse, and DisplayPort video console.
Doing so with ease, the CS782DP provides three convenient switching methods - using a remote port selector, mouse, or hotkeys for flexible access to any computer connected to the installation. The product even provides premium audio support for a complete multimedia solution. To round off the entire experience, the streamlined, space-saving design of CS782DP also makes it ideal for any working environment.
With its rich feature set, the CS782DP is designed to surpass all requirements in graphic design, animation, and video-editing applications.
Tech Specs
| USB | Yes |
|---|---|
| Depth | 3.7" |
| Width | 3.7" |
| Height | 1.1" |
| Brand Name | ATEN |
| DisplayPort | Yes |
| Form Factor | Rack-mountable |
| Manufacturer | ATEN Technology, Inc |
| Product Name | CS782DP 2-Port USB DisplayPort KVM Switch |
| Product Type | KVM Switchbox |
| Input Voltage | 5 V DC |
| Product Model | CS782DP |
Show all 25 specsShow fewer
| Package Contents | <ul> <li>CS782DP 2-Port USB DisplayPort KVM Switch</li> <li>2 x DisplayPort 1.2 Cable (1.5m/5ft)</li> <li>2 x USB Cable (USB-A to USB-B; 1.8m/6ft)</li> <li>2 x Audio Cable (1.8m/6ft)</li> <li>1 x Remote Port Selector</li> <li>1 x User Instructions</li> </ul> |
|---|---|
| Country of Origin | China |
| Packaged Quantity | 1 |
| Input Voltage Range | 5V DC |
| Number of USB Ports | 4 |
| Weight (Approximate) | 4.23 oz |
| Number of DisplayPorts | 3 |
| Environmentally Friendly | Yes |
| Manufacturer Part Number | CS782DP |
| Maximum Video Resolution | 4096 x 2160 |
| Manufacturer Website Address | http://www.aten.com/us/en/ |
| Number of Computers Supported | 2 |
| Number of Local Users Supported | 1 |
