IOGEAR

2PORT DISPLAYPORT SECURE KVM WITH CAC NIAP V3.0

SKU: 3GR931VPN: GCS1412TAA3

2PORT DISPLAYPORT SECURE KVM WITH CAC NIAP V3.0

Key Features

  • NIAP-Certified PP3.0
  • Validated to Protection Profile v3.0 for Peripheral Sharing Switches
  • CAC & Biometrics Support
  • Dedicated peripheral port for authorized CAC readers only and supported Biometrics readers1
  • 8-Port Dual View Dual-Link DVI Secure KVM Switch
  • One USB console controls 8 secure computers on 2 displays
  • Superior 4K UHD Video Resolution
  • Dual-Link Resolution: 2560 x 1600; 4K UHD Resolution: 3840 x 2160 @30Hz2
  • Port Selection via Push-Button for Enhanced Security
  • Keyboard restrictions - OSD & hotkey methods are not allowed
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

2-Port Secure DisplayPort KVM Computer Switch - Protection Profile 3.0

IOGEAR's 2-Port DisplayPort Secure KVM Switch is NIAP-certified and compliant with PP3.0 (Protection Profile for Peripheral Sharing Switch version 3.0) requirements, satisfying the latest security requisites set by the U.S. Department of Defense for peripheral sharing switches.

Common criteria compliance ensures maximum information security while sharing a single set of approved HIDs - keyboards, mice, speakers, CAC readers, and Microsoft Biometric Readers - between multiple computers. Conformity with Protection Profile v3.0 certifies that non-approved USB peripherals will be rejected and cannot be connected to the Secure KVM, providing high-level security, protection, and data safekeeping.

Active Tamper-Proof System

The IOGEAR Secure KVM Switch's hardware security is comprised of tamper-evident seals, active chassis intrusion detection, and tamper-proof hardware. Embedded software security allows administrators to grant controlled USB port access for keyboards, mice and other devices while ignoring commands from non-HIDs when switching between ports.The onboard software restricts mouse and hotkey commands while clearing the keyboard's buffer when switching ports while ensuring data travels isolated on each port preventing exposure.

With the combination of physical and software security, IOGEAR Secure KVM series consolidates multiple workstations with varying security classification levels using one keyboard, monitor, and mouse (KVM) console.

Superior Video Quality

The 2-Port DisplayPort Secure KVM supports a single view display and superior 4K Ultra-HD resolutions to 3840 x 2160 @ 30Hz. For a variety of single or dual-view display connections including DVI, HDMI and DisplayPort interfaces, see the Secure KVM selector.

Tech Specs

2PORT DISPLAYPORT SECURE KVM WITH CAC NIAP V3.0 specifications
USBYes
Depth6.4"
Width13.1"
Height1.7"
PS/2 PortYes
Brand NameIOGEAR
DisplayPortYes
Form FactorRack-mountable
ManufacturerIOGEAR, Inc
Product Name2-Port DisplayPort Secure KVM Switch (TAA)
Product TypeKVM Switchbox
Input Voltage120 V AC
Show all 29 specs
Product ModelGCS1412TAA3
TAA CompliantYes
Package Contents<ul> <li>2-Port DisplayPort Secure KVM Switch (TAA)</li> <li>1 x Power Cord</li> <li>1 x Manual</li> <li>1 x Warranty</li> </ul>
Country of OriginTaiwan
Packaged Quantity1
Input Voltage Range120V AC to 230V AC
Number of USB Ports7
Number of PS/2 Ports2
Weight (Approximate)3.70 lb
Number of DisplayPorts3
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
Environmentally FriendlyYes
Manufacturer Part NumberGCS1412TAA3
Maximum Video Resolution3840 x 2160
Manufacturer Website Addresshttp://www.iogear.com
Number of Computers Supported2
Number of Local Users Supported1
