CYBERPOWER

15A PDU RM 1U 1800J SURGE 12OUT 5-15R 120V 15 CORD 3YR-WTY

SKU: 9GM243VPN: CPS1215RMS

15A PDU RM 1U 1800J SURGE 12OUT 5-15R 120V 15 CORD 3YR-WTY

Key Features

  • Surge suppression: 1800 J
  • Volts: 120 V
  • Circuit breaker: 15 A
  • Outlet type: (12) NEMA 5-15R (6 front, 6 rear)
  • Surge-protected outlets: Yes
  • Power cord: 15 ft
  • Rack size: 1U rackmount
  • EMI/RFI Filtration: Yes
  • Warranty: 3 year
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

Engineered for the most demanding applications, the professional-grade Rackbar CPS1215RMS safeguards systems and networking equipment by absorbing spikes in energy caused by storms and electrical power surges. Designed for network environments, the CPS1215RMS also performs superbly for home office use, providing 1800 joules of protection, 15-Amp electrical capacity with circuit breaker, and 12 surge-protected outlets (6 front, 6 rear). Industrial-grade metal housing keeps this Rackbar performing flawlessly. The CPS1215RMS has a 1U racksize and can be mounted horizontally.

Features of the CPS1215RMS include an EMI/RFI noise filter, industrial-grade metal housing, AC power cord (15 ft.). The CPS1215RMS also comes with a three-year limited warranty.

Tech Specs

15A PDU RM 1U 1800J SURGE 12OUT 5-15R 120V 15 CORD 3YR-WTY specifications
Depth4.8"
Width17.3"
Height1.8"
FeaturesOverload Protection
Brand NameCyberPower
Form FactorRack-mountable
Rack Height1U
Receptacles12 x NEMA 5-15R
Color FamilyBlack
ManufacturerCyberPower Systems, Inc
Product NameCPS-1215RMS
Product TypeSurge Suppressor/Protector
Show all 39 specs
Clamp Voltage400 V
Input Voltage120 V AC
Product ColorBlack
Product ModelCPS1215RMS
Output Voltage120 V AC
Product FamilyRackbar Surge
Product SeriesRackbar Surge
Circuit BreakerYes
Protection TypeSurge/Lightning Protection
Product MaterialMetal
Application/UsageNetwork Device
Status Indicators<ul><li>Power On (Yellow)</li><li>Ground (Green)</li><li>Surge (Red)</li></ul>
Plug/Connector TypeNEMA 5-15P
Surge Energy Rating1800 J
Weight (Approximate)5 lb
Maximum Spike Voltage6 kV AC
Maximum Surge Current90 kA
Additional Information<li>Physical Dimensions - (WxHxD) (cm) : 43.82 x 4.45 x 12.07 (cm)</li><li>Physical Dimensions - (WxHxD) (in) : 17.25 x 1.75 x 4.75 (in)</li><li>Physical Dimensions - (WxHxD) (mm) : 438 x 44 x 121 (mm)</li><li>Weight (kg) : 2.27</li><li>Weight (lb) : 5</li><li>Shipping Dimensions - (WxHxD) (cm) : 25.4 x 5.77 x 52.07 (cm)</li><li>Shipping - Dimensions (WxHxD, in) : 10.0 x 2.27 x 20.5 (in)</li><li>Shipping - Dimensions (WxHxD, mm) : 254.0 x 57.66 x 520.7 (mm)</li><li>Shipping - Weight (kg) : 9.41</li><li>Shipping - Weight (lb) : 20.75</li><li>Circuit Breaker : 15 A</li><li>Cord Length : 15 ft (4.6 m)</li><li>Input Plug Type : NEMA 5-15P</li><li>Maximum Input Current : 15A</li><li>Nominal Input Voltage : 120 VAC</li><li>Plug Style : Straight</li><li>Switch : Lighted On/Off</li><li>Nominal Output Voltage : 120 VAC</li><li>Outlets - Front : 6</li><li>Outlets - Rear : 6</li><li>Outlets - Total : 12</li><li>Outlet Type COMPUTED : 12 - NEMA 5-15R</li><li>Overload Protection : 15A</li><li>USB Charge Port : No</li><li>Clamping Voltage : 400V (H-N, N-G)</li><li>EMI/RFI Filtration COMPUTED : 150 KHz</li><li>Maximum Surge Current : 90000 A</li><li>Maximum Surge Current H-G : 30000 A</li><li>Maximum Surge Current H-N : 30000 A</li><li>Maximum Surge Current N-G : 30000 A</li><li>Maximum Surge Voltage : 6000 V</li><li>Surge Suppression (Joules) : 1800 J</li><li>Clamping Voltage : 400V (H-N, N-G)</li><li>EMI/RFI Filtration COMPUTED : 150 KHz</li><li>Maximum Surge Current : 90000 A</li><li>Maximum Surge Current H-G : 30000 A</li><li>Maximum Surge Current H-N : 30000 A</li><li>Maximum Surge Current N-G : 30000 A</li><li>Maximum Surge Voltage : 6000 V</li><li>Surge Suppression (Joules) : 1800 J</li><li>Color : Black</li><li>Cord Retention Tray/Cord Organizers : Yes</li><li>Form Factors Supported : 1U Rackmount</li><li>Material of Construction : Metal</li><li>Rack Height : 1U</li><li>Operating Elevation : 0 - 10000 ft (0 - 3048 m)</li><li>Operating Relative Humidity : 0 - 95 % (non-condensing)</li><li>Operating Temperature : 32 - 95 °F (0 - 35 °C)</li><li>Storage Elevation : 0 - 50000 ft (0 - 15239 m)</li><li>Storage Temperature : 5 - 113 °F (-15 - 45 °C)</li><li>Environmental : RoHS Compliant</li><li>Safety : UL Recognized</li><li>CEG Amount : $0</li><li>Connected Equipment Guarantee : No</li><li>Product Warranty : 3 Year Limited Warranty</li>
Power Cord/Cable Length15 ft
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
Manufacturer Part NumberCPS-1215RMS
Certifications & StandardsUL Recognized
Maximum Storage Temperature113°F (45°C)
Minimum Storage Temperature5°F (-15°C)
Manufacturer Website Addresshttps://www.cyberpowersystems.com/
Maximum Operating Temperature95°F (35°C)
Minimum Operating Temperature32°F (0°C)
