BLACK BOX CORPORATION

10/100/1000 1000 0.5K SC MEDCON US PS

SKU: SG3391VPN: LMC4002A

10/100/1000 1000 0.5K SC MEDCON US PS

Key Features

  • Ultra compact, weighing only 2.5 ounces.
  • USB-powered for portability, or use it with the included power adapter.
  • UTP port supports 10/100/1000BASE-T.
  • Supports Jumbo Ethernet frames up to 10,240 bytes.
  • LED indicators for power, UTP, and fiber status.
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

Bring fiber to the desktop and other tight spaces. The Micro Mini Media Converter is ideal for bringing fiber to the desktop and for mobile applications where light weight compact size and low power requirements are critical. Weighing only 2.5 ounces and about the length of a house key this ultra-compact media converter is portable yet powerful. For extra versatility it can be USB-powered making it easy to provide fiber connectivity to locations where AC or DC power is unavailable for instance field-deployed fiber-to-the-laptop. For easy portability this tiny converter conveniently slips into a pocket or laptop carrying case. The converter is plug-and-play with an RJ-45 port that autonegotiates for speed duplex mode and crossover functions for PCs with 10BASE-T 100BASE-TX and 1000BASE-T Ethernet. On the fiber side the converter has an SC connector for connection to multimode fiber. Because it can be powered through a computer's USB 1.0 or 2.0 port the Micro Mini Media Converter is ideal for connections to fiber in areas where a spare power outlet may not be available. When plugged into a computer's USB port the media converter shuts down automatically when you turn off the computer which saves energy.

Tech Specs

10/100/1000 1000 0.5K SC MEDCON US PS specifications
DVINo
USBYes
Depth2.3"
Width1.8"
Height0.8"
Brand NameBlack Box
Form FactorWall Mountable
ManufacturerBlack Box Corporation
Power SourceAC Adapter
Product LineMicro Mini
Product NameMicro Mini LMC4002A Transceiver/Media Converter
Product TypeTransceiver/Media Converter
Show all 33 specs
SC Port TypeDuplex
Product ModelLMC4002A
TAA CompliantYes
Product FamilyMicro Mini
Management PortNo
Network (RJ-45)Yes
Package Contents<ul> <li>Micro Mini LMC4002A Transceiver/Media Converter</li> <li>Power Adapter</li> </ul>
Country of OriginUnited States
Network Technology1000Base-X
Number of SC Ports1
Ethernet TechnologyGigabit Ethernet
Fiber Mode SupportedMulti-mode
Media Type SupportedOptical Fiber
Weight (Approximate)2.50 oz
Total Number of Ports2
Environmentally FriendlyYes
Manufacturer Part NumberLMC4002A
Maximum Distance Supported0.50 km
Fiber Optic Cable Wavelength850 nm
Manufacturer Website Addresshttp://www.blackbox.com
Number of Network (RJ-45) Ports1
