USB 3.1 2 PORT PCIE HOST ADAPTER TYPE A

SKU: 9BK984VPN: JU-P20912-S2

In Stock

Request pricing

Pricing for this item is configured per-order. Add it to your inquiry below and we'll send a tailored quote.

Key Features

Adds a port to your PC through the PCI Express 3.0 x4 interface
Connect USB-enabled devices via 2 USB ports
USB Adapter has a non-volatile memory which is beneficial for your PC firewall needs

Adding to inquiry lets you bundle multiple products into a single quote request.

Adds two USB 3.1 Type-A ports to your desktop computer via an available PCI Express slot

Complies with PCI-Express 3.0 standard
Supports the latest USB generation 3.1 Gen 2 with data transfer rate up to 10Gb/s
Supports plug-n-play, hot-swapping, and backwards compatible with USB 1.1 / 2.0 / 3.0
Each USB port provides up to 900mA power output to better support the power consumption of your connected device
Each USB port features independent over-current protection to further protect your device
Built-in 15-pin SATA power connector connects to the system power supply, as needed, to ensure sufficient power is supplied to the USB ports
Dual-profile design installs into different form factor system chassis with the included full and low profile brackets

USB 3.1 2 PORT PCIE HOST ADAPTER TYPE A specifications
Width	3.9"
Height	0.8"
Length	4.7"
Brand Name	SIIG
Form Factor	Plug-in Card
Manufacturer	SIIG, Inc
Product Name	USB 3.1 2-Port PCIe Host Adapter - Type-A
Product Type	USB Adapter
Product Color	Black
Host Interface	PCI Express 3.0 x4
Package Contents	<ul> <li>USB 3.1 2-Port PCIe Host Adapter - Type-A</li> <li>Spare Low Profile Bracket</li> <li>Installation Guide</li> </ul>
Country of Origin	Switzerland

Show all 20 specs

Platform Supported	PC
Weight (Approximate)	1.76 oz
Number of USB 3.1 Ports	2
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Environmentally Friendly	Yes
Manufacturer Part Number	JU-P20912-S2
Total Number of USB Ports	2
Manufacturer Website Address	http://www.siig.com
