PSI5 1000VA 1U RACK UPS
PSI5 1000VA 1U RACK UPS
Key Features
- POWER PROTECTION: The 1kVA UPS has AVR to correct power disturbances.
- SPACE-SAVING 1U RACK: Get similar features as a 2U battery backup in a compact 1U rack space.
- MORE USABLE POWER: This single phase line interactive UPS has 0.9 output power factor.
- REMOTE MANAGEMENT CAPABILITY: Add a communication card to this UPS to monitor devices remotely.
- PROGRAMMABLE OUTLETS: Get 5 total outlets with 2 programmable outlets to prioritize critical loads.
Adding to inquiry lets you bundle multiple products into a single quote request.
Overview
The Vertiv Liebert PSI5 1kVA UPS is designed to protect and extend the life of your electronic devices in school, home and office. This 1U rack mount UPS offers cost-effective protection from downtime and damage caused by power outages, brownouts, sags, surges or noise interference. Automatic Voltage Regulation (AVR) extends battery life and safeguards critical equipment. Voltage regulation is from 83 to 159 VAC without using the battery. With advanced pure sine wave output, this line interactive UPS ensures availability of critical IT applications like network closets and small data centers. This battery backup allows orderly shutdown of critical equipment. It takes less than 6 milliseconds transfer time to battery. Add an optional Vertiv Liebert Unity communication card and remotely monitor up to 50 UPS systems through the free Vertiv Trellis Power Insight Application. It has a 2-year Vertiv UPS warranty with optional extensions for up to 5 years total coverage.
Tech Specs
| AVR | Yes |
|---|---|
| Depth | 17.7" |
| Phase | Single Phase |
| Width | 17.2" |
| Height | 1.7" |
| EPO Port | Yes |
| Brand Name | Vertiv Liebert |
| Energy Star | No |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Serial Port | No |
| Battery Size | 6V |
Show all 53 specsShow fewer
| Manufacturer | Vertiv |
|---|---|
| Product Name | PSI5-1000RM1201U UPS |
| Product Type | Line-interactive UPS |
| Hot Swappable | Yes |
| Input Voltage | 120 V AC |
| Product Model | PSI |
| TAA Compliant | No |
| Transfer Time | 4 ms |
| Waveform Type | Pure Sine Wave |
| Output Voltage | 110 V AC |
| Product Family | PSI5 |
| Product Series | PSI5 |
| Input Frequency | 65 Hz |
| Network (RJ-45) | No |
| Receptacle Type | NEMA 5-15R |
| Battery Capacity | 9000 mAh |
| Output Frequency | 60 Hz |
| Package Contents | <ul> <li>PSI5-1000RM1201U UPS</li> <li>Rack Mount Ears</li> <li>USB Cable</li> <li>Safety Manual</li> <li>Quick Installation Guide </li> </ul> |
| Application/Usage | Home |
| Battery Chemistry | Lead Acid |
| Country of Origin | China |
| DC System Voltage | 6 V DC |
| Receptacle Detail | 5 x NEMA 5-15R |
| Software Included | Power Insight 2.2 |
| Load Capacity (VA) | 1000 VA |
| Input Voltage Range | 75 V AC - 146 V AC |
| Number of Batteries | 4 |
| Plug/Connector Type | NEMA 5-15P |
| Load Capacity (Watt) | 900 W |
| Weight (Approximate) | 36.40 lb |
| Battery Characteristics | Valve-regulated, Non-spillable |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Environmentally Friendly | Yes |
| Manufacturer Part Number | PSI5-1000RM1201U |
| USB (HID Compliant) Port | Yes |
| Backup/Run Time (Full Load) | 5 Minute |
| Backup/Run Time (Half Load) | 13 Minute |
| Maximum Operating Elevation | 9842.52 ft |
| Manufacturer Website Address | http://www.vertiv.com/ |
| Maximum Operating Temperature | 104°F (40°C) |
| Typical Battery Recharge Time | 6 Hour |
