PSI5 750VA TOWER UPS
PSI5 750VA TOWER UPS
Key Features
- POWER PROTECTION: The 750VA UPS has AVR to correct power disturbances.
- MORE USABLE POWER: This single phase line interactive UPS has 0.9 output power factor.
- NO INSTALLATION: This plug-and play battery backup does not need installation or rack space.
- REMOTE MANAGEMENT CAPABILITY: Add a communication card to this UPS to monitor devices remotely.
- PROGRAMMABLE OUTLETS: Get 5 total outlets with 2 programmable outlets to prioritize critical loads.
Adding to inquiry lets you bundle multiple products into a single quote request.
Overview
The Vertiv Liebert PSI5 uninterruptible power supply (UPS) is designed to protect and extend the life of your electronic devices in school, home and office. This 750VA UPS tower offers cost-effective protection from downtime and damage caused by power outages, brownouts, sags, surges or noise interference. Automatic Voltage Regulation (AVR) extends battery life and safeguards critical equipment. Voltage regulation is from 83 to 159 VAC without using the battery. With advanced pure sine wave output, this line interactive UPS ensures availability of critical IT applications like network closets and small data centers. This battery backup allows orderly shutdown of critical equipment. It takes less than 6 milliseconds transfer time to battery. Add an optional Vertiv Liebert Unity communication card and remotely monitor up to 50 UPS systems with free Vertiv Trellis Power Insight Application. It has a 2-year Vertiv UPS warranty with optional extensions for up to 5 years total coverage.
Tech Specs
| AVR | Yes |
|---|---|
| Depth | 14.6" |
| Phase | Single Phase |
| Width | 5.7" |
| Height | 8.7" |
| EPO Port | Yes |
| Brand Name | Vertiv Liebert |
| Energy Star | No |
| Form Factor | Tower |
| Serial Port | No |
| Battery Size | 12V |
| Manufacturer | Vertiv |
Show all 53 specsShow fewer
| Product Name | PSI5-750MT120 UPS |
|---|---|
| Product Type | Line-interactive UPS |
| Hot Swappable | Yes |
| Input Voltage | 120 V AC |
| Product Model | PSI |
| TAA Compliant | No |
| Transfer Time | 4 ms |
| Waveform Type | Pure Sine Wave |
| Output Voltage | 100 V AC |
| Product Family | PSI5 |
| Product Series | PSI5 |
| Input Frequency | 65 Hz |
| Network (RJ-45) | Yes |
| Receptacle Type | NEMA 5-15R |
| Battery Capacity | 9000 mAh |
| Output Frequency | 60 Hz |
| Package Contents | <ul> <li>PSI5-750MT120 UPS</li> <li>USB Cable</li> <li>Safety Manual</li> <li>Quick Installation Guide </li> </ul> |
| Application/Usage | Data Center |
| Battery Chemistry | Lead Acid |
| Country of Origin | China |
| DC System Voltage | 12 V DC |
| Receptacle Detail | 5 x NEMA 5-15R |
| Software Included | Power Insight 2.2 |
| Load Capacity (VA) | 750 VA |
| Dataline Protection | RJ-45 |
| Input Voltage Range | 75 V AC - 146 V AC |
| Number of Batteries | 2 |
| Plug/Connector Type | NEMA 5-15P |
| Load Capacity (Watt) | 675 W |
| Weight (Approximate) | 24.70 lb |
| Battery Characteristics | Valve-regulated, Non-spillable |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Environmentally Friendly | Yes |
| Manufacturer Part Number | PSI5-750MT120 |
| USB (HID Compliant) Port | Yes |
| Backup/Run Time (Full Load) | 6 Minute |
| Backup/Run Time (Half Load) | 18 Minute |
| Maximum Operating Elevation | 9842.52 ft |
| Manufacturer Website Address | http://www.vertiv.com/ |
| Maximum Operating Temperature | 104°F (40°C) |
| Typical Battery Recharge Time | 8 Hour |
