EMBEDDED 8PORT ETHERNET SWITCH TEMPERATURE RANGE OF -40F TO +176F

SKU: 5DB378VPN: SW-108

In Stock

$128.89

Actual pricing depends on volume, configuration, and current promotions. Reach out and we'll put together a real quote — often below this number.

Key Features

8 Port Ethernet Switch
Ready for embedded applications
Redundant dual power inputs: +5V to +30V DC
Industrial operating temp range -40°C to +80°C / -40°F to +176°F
Lifetime Warranty and Support

Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

Industrial Ethernet 8 Port unmanaged switch. Galvanically Isolated Ports. Industrial temperature range of -40°C to +80°C (-40°F to 176°F) and dual input redundant power supply with wide voltage range means it can be powered from USB or on the 24V factory floor. Power terminal is removable with numbered pins for easy wiring. Power consumption is optimised based on the status of the link device. No software required. Ideal for embedded applications.

Tech Specs

EMBEDDED 8PORT ETHERNET SWITCH TEMPERATURE RANGE OF -40F TO +176F specifications
Depth	3.5"
Width	3.7"
Height	0.8"
Modular	No
Brand Name	Brainboxes
Manageable	No
Stack Port	No
Uplink Port	No
Manufacturer	Brainboxes Limited
Power Source	USB
Product Name	Industrial Embeddable 8 Port Ethernet Switch
Product Type	Ethernet Switch

Show all 27 specs

Product Model	SW-108
TAA Compliant	Yes
Layer Supported	2
Package Contents	<ul> <li>Industrial Embeddable 8 Port Ethernet Switch</li> <li>Quick Start Guide</li> </ul>
Country of Origin	United Kingdom
Network Technology	10/100Base-T
Ethernet Technology	Fast Ethernet
Media Type Supported	Twisted Pair
Weight (Approximate)	3.10 oz
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Environmentally Friendly	Yes
Manufacturer Part Number	SW-108
Port/Expansion Slot Details	8 x Fast Ethernet Network
Manufacturer Website Address	http://www.brainboxes.com
Total Number of Network Ports	8
