8PORT DIGITAL I/O EXPANSION BOX FOR VK CONTROL SYSTEM

SKU: 7VY994VPN: VK258

Out of Stock

$444.98

Actual pricing depends on volume, configuration, and current promotions. Reach out and we'll put together a real quote — often below this number.

Key Features

Provides 8 Digital I/O channels to expand the ATEN Control System
Up to eight VK258 expansion boxes can be added to a single ATEN Controller
Flexible Deployment - connects to an ATEN Controller via an Ethernet connection
ID Switch pairs the VK258 with a controller to instantly configure the network settings
One DC output allows you to power I/O or other low-voltage devices that require an extra power supply
Supports Power over Ethernet (PoE) or DC power supply
Firmware upgradable through USB, firmware upgrade tool, or web interface

Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

The VK258 8-Channel Digital I/O Expansion Box provides an additional eight channels of digital input/output for a flexible expansion of the ATEN Control System. This allows users to control more digital I/O devices, such as various sensors, dry contact devices, PCs, and motor-driven devices in environments where more devices need to be centrally controlled. With the advantage of the Ethernet-based connection, the expansion box easily connects to the ATEN Controller via a LAN connection from different locations across a network.

Tech Specs

8PORT DIGITAL I/O EXPANSION BOX FOR VK CONTROL SYSTEM specifications
Width	3"
Height	1.7"
Brand Name	VanCryst
Manufacturer	ATEN Technology, Inc
Power Source	DC
Product Line	Professional
Product Name	VK258 8-Channel Digital I/O Expansion Box
Product Type	Digital I/O Expansion Box
Product Model	VK258
Product Family	Professional
Product Material	Metal
Application/Usage	PC
