2000W INVERTER CHARGER 120V 12VDC ATS RJ45 HARDWIRE
2000W INVERTER CHARGER 120V 12VDC ATS RJ45 HARDWIRE
Key Features
- Delivers clean 120V AC power from AC or DC power source
- 2000W continuous output power; 4000W peak power
- Auto-transfer switching option for UPS operation
- Protects against blackouts, surges and EMI/RFI line noise
- Rugged polycarbonate housing resists moisture and impact
Adding to inquiry lets you bundle multiple products into a single quote request.
Overview
The APS2012 2000W PowerVerter APS 12V DC 120V AC Inverter/Charger is a reliable power source for a wide variety of equipment ranging from power tools and pumps to portable lighting and computer equipment in heavy-load conditions. With no fumes, fuel or excess noise, it's an excellent alternative to generator power.
The DC-to-AC inverter features an automatic line-to-battery transfer switch and integrated charging system that allow it to work as a vehicle inverter, standalone AC power source or extended-run UPS. It delivers 2000W of continuous power, 3000W up to one hour, or 4000W of peak power up to 10 seconds during equipment startup or cycling. An automatic overload detector, cooling fan and resettable AC circuit breakers protect the unit from damage.
Designed for easy installation in RVs, commercial and fleet vehicles, emergency vehicles and construction equipment, the APS2012 converts stored power from any 12V battery or automotive DC source to safe, stable, computer-grade AC power for unlimited runtime. When hardwired to an external 120V AC source, the unit keeps the user-supplied battery charged via a three-stage 25/100A selectable charging system while simultaneously delivering AC power to connected equipment.
When used as a UPS, the APS2012 responds to blackouts and brownouts with an automatic, instantaneous transfer to battery-derived AC output. LEDs on the unit indicate load level, battery charge level, shutdown status and system fault status.
Tech Specs
| Depth | 16.3" |
|---|---|
| Width | 8.5" |
| Height | 7.3" |
| Brand Name | Tripp Lite series |
| Receptacles | Hardwired |
| Color Family | Black |
| Manufacturer | Eaton Corporation |
| Product Line | PowerVerter |
| Product Name | 2000W PowerVerter APS 12VDC 120V Inverter/Charger |
| Product Type | Power Inverter |
| Input Voltage | 12 V DC |
| Product Color | Black |
Show all 27 specsShow fewer
| Waveform Type | Pulse-width Modulated Sine Wave |
|---|---|
| Output Voltage | 120 V AC |
| Product Series | APS |
| Peak Power Load | 4000 W |
| Package Contents | <li>2000W PowerVerter APS 12VDC 120V Inverter/Charger</li><li>Owner's Manual</li> |
| Country of Origin | China |
| Maximum Frequency | 60 Hz |
| Input Voltage Range | 10 V DC - 15 V DC |
| Plug/Connector Type | Hardwired |
| Weight (Approximate) | 40 lb |
| Continuous Power Load | 2000 W |
| Additional Information | <ul><li>Extended Run UPS Configure as a UPS for long-term battery support of telecom systems, security alarms, computer systems and various other motorized and electronic loads.</li><li>Standalone Power Alternative power source for use in off-grid, backwoods, alternative energy and export applications where commercial power is not continuously available.</li><li>Automotive Connect to an automotive electrical system to run power tools, computers, electronic test equipment, home entertainment and other AC appliances in fleet service vehicles, over-the-road trucks, campers, RVs, minivans and more.</li><li>Allows unlimited runtime capability by allowing the use any number of user-supplied batteries</li><li>Frequency control for operating stability</li><li>User supplies cabling, 4 gauge or larger recommended</li><li>Cooling Method: Fan</li><li>Auto-transfer to enable battery charging and automatic UPS support for blackouts and brownouts</li><li>RJ45 port allows connection of APS remote switch</li><li>Battery runtime is dependent upon the size and number of user-supplied batteries in 12V configuration</li><li>Advanced 20/60 amp selectable , 3-stage battery charger and selector switch for gel or wet cell batteries</li><li>Resettable circuit breaker protects APS against system overload</li></ul><p><b>Low voltage transfer to battery power:</b></p><ul><li>User configurable to 75V, 85V, 95V and 105V</li></ul><p><b>High voltage transfer to battery power:</b></p><ul><li>User configurable to 135V, 145V</li></ul><p><b>LED Alarm and Switches:</b></p><ul><li>Front Panel LEDS : Six LEDS</li><li>Switches : Three position on/off/remote switch enables simple on/off power control plus auto or remote setting</li></ul> |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Manufacturer Part Number | APS-2012 |
| Manufacturer Website Address | http://www.eaton.com |
