2-PORT VGA RECEIVER

SKU: RP6553VPN: AC555A-REM-R2

2-PORT VGA RECEIVER

In Stock

$177.28

Actual pricing depends on volume, configuration, and current promotions. Reach out and we'll put together a real quote — often below this number.

Key Features

Works with the 4-port VGA Transmitter (AC555A-4-R2) to extend V GA video up to 500 feet.
An equalization (gain) control enables you to fine-tune the picture.
Has a 2-kV avalanche diode, which provides greater electrostatic discharge (ESD) protection and more reliable operation.
Connects to two VGA monitors.

Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

Connect two remote monitors in a VGA Transmitter extender application. Works with the 4-port VGA Transmitter (AC555A-4-R2) to extend V GA video up to 500 feet. An equalization (gain) control enables you to fine-tune the picture. Has a 2-kV avalanche diode which provides greater electrostatic discharge (ESD) protection.

Tech Specs

2-PORT VGA RECEIVER specifications
VGA Out	Yes
Brand Name	Black Box
Manufacturer	Black Box Corporation
Product Name	VGA Receiver, 2-Port
Product Type	Video Extender Receiver
Input Voltage	110 V AC
Graphics Modes	XGA
Receiver Depth	2.30"
Receiver Width	3.30"
Network (RJ-45)	Yes
Receiver Height	0.60"
Country of Origin	Taiwan

Show all 25 specs

Media Type Supported	Twisted Pair
Number of VGA Outputs	2
Connectivity Technology	Wired
Environmental Compliance	Waste Electrical and Electronic Equipment Directive (WEEE)
Environmentally Friendly	Yes
Manufacturer Part Number	AC555A-REM-R2
Maximum Video Resolution	1024 x 768
Maximum Operating Distance	500 ft
Twisted Pair Cable Standard	Category 5
Manufacturer Website Address	http://www.blackbox.com
Receiver Weight (Approximate)	6.40 oz
Number of Network (RJ-45) Ports	1
Number of Output Devices Supported	2
