2 PORT USB 3.0 PCI EXPRESS CARD USB PCIE ADAPTER CONTROLLER CARD

SKU: RZ0826VPN: PEXUSB3S23

Limited Stock

$20.77

Actual pricing depends on volume, configuration, and current promotions. Reach out and we'll put together a real quote — often below this number.

Key Features

Provides two external USB 3.2 Gen 1 connections
Supports data rates up to 5 Gbps
SATA power connector (required) provides up to 900mA per USB port
Compliant with PCI Express 2.0 specifications
Fully compliant with USB 3.2 Gen 1 rev 1.0 and Intel xHCI rev 1.0 specifications
Backward compatible with USB 2.0 and USB 1.0/1.1 devices
Includes a Low Profile/half-height installation bracket

Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

The PEXUSB3S23 2-Port PCI Express USB 3.2 Gen 1 Card lets you add two USB 3.2 Gen 1 ports to any PCI Express-enabled computer system. The USB card requires SATA power for functionality, and delivers 900mA of power per port to USB 3.2 Gen 1 bus-powered devices (500mA for USB 2.0) via your computers SATA power connector. The PCIe USB 3.2 Gen 1 adapter is compliant with USB 3.2 Gen 1 standards for data transfer speeds up to 5 Gbps, while still offering backward compatibility with existing USB 2.0 / 1.1 devices. For added versatility, the controller card is equipped with a standard profile bracket and includes a low-profile/half-height bracket for installation in small form-factor computers. Backed by a StarTech.com 2-year warranty and free lifetime technical support. More from the Manufacturer

Tech Specs

2 PORT USB 3.0 PCI EXPRESS CARD USB PCIE ADAPTER CONTROLLER CARD specifications
Width	0.8"
Height	4.7"
Length	3.1"
Brand Name	StarTech.com
Form Factor	Plug-in Card
Color Family	Black
Manufacturer	StarTech.com
Product Name	2 Port PCI Express PCIe SuperSpeed (5Gbps) USB 3.0 Controller Card w/ SATA Power
Product Type	USB Adapter
UASP Support	No
Product Color	Black
Host Interface	PCI Express x1

Show all 26 specs

Package Contents	<ul> <li>2 Port PCI Express PCIe SuperSpeed (5Gbps) USB 3.0 Controller Card w/ SATA Power</li> <li>1 x Low Profile Bracket</li> <li>1 x Driver CD</li> <li>1 x Instruction Manual</li> </ul>
Country of Origin	China
Packaged Quantity	1 Each
Platform Supported	PC
Number of SATA Ports	1
Weight (Approximate)	1.52 oz
Additional Information	<li>Windows® 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64)</li><li>Windows Server® 2012, 2008 R2, 2003</li>
Number of USB 3.2 Ports	2
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Environmentally Friendly	Yes
Manufacturer Part Number	PEXUSB3S23
Total Number of USB Ports	2
Operating System Supported	Windows 8
Manufacturer Website Address	http://www.startech.com
