STARTECH.COM

100M 4K HDMI OVER CAT6 EXTENDER 4K UHD POC HDMI ETHERNET EXTENSION

SKU: 5KR141VPN: ST121HDBT20L

100M 4K HDMI OVER CAT6 EXTENDER 4K UHD POC HDMI ETHERNET EXTENSION

Key Features

  • Get astonishing video quality at impressive distances with UHD 4K 60Hz resolution at up to 70 m (230 ft.) and 1080p 60Hz resolutions at up to 100 m (328 ft.)
  • Hassle-free setup with video and power over a single CAT5e or CAT6 cable
  • Sleek professional installation with optional mounting hardware included
  • Remotely control your video source from the location of your remote display, with support for IR extension
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

This HDMI Over CAT6 extendertransmitsyour HDMI audio/video signal to a remote location up to 100 m (328 ft.)away. Get4K at 60Hz from 70 m (230 ft.)away This HDMI over CAT6 extender maintains your Ultra HD 4K picture quality, even at 70 m (230 ft.)away from your video source. If you're not running 4K video, this extender supports High-Definition 1080p 60Hz and lower resolutions at even greater distances, up to 100 m (328 ft.)from your HDMI source. With full support for your HDMI 2.0 equipment, including4K resolution at 60Hz, this extender can transmit at a bandwidth of up to 18Gbps, making it the ideal solution for high-resolution tasks requiring the highest color detail. For smoother video and color transitions, the extender offers 4:4:4 chroma subsampling via visually lossless compression, meaning every pixel gets its own unique color. Simplify your setup The HDMI Extender Over CAT6 offers a hassle-free solution for your digital signage project. The extender only requires a single CAT5e or CAT6 cable, so you extend an HDMI signal using existing infrastructure that's already in your building. Plus, this HDMI extender supports Power Over Cable (POC), which means you'll only need one power adapter connected to either your transmitter or receiver. Mounting hardware is also included for discreet, professional installation. The ST121HDBT20L is TAA compliant and backed by a 2-year StarTech.com warranty with free lifetime technical support.

Tech Specs

100M 4K HDMI OVER CAT6 EXTENDER 4K UHD POC HDMI ETHERNET EXTENSION specifications
HDMI InYes
HDMI OutYes
Brand NameStarTech.com
Color FamilyBlack
ManufacturerStarTech.com
Product NameHDMI Over CAT6 Extender - Power Over Cable - Up to 100 m (328 ft.)
Product TypeVideo Extender Transmitter/Receiver
Product ColorBlack
TAA CompliantYes
Graphics Modes4K
Receiver Depth4"
Receiver Width3"
Show all 36 specs
Network (RJ-45)Yes
Receiver Height1"
Package Contents<ul> <li>1 x HDMI Over CAT6 Transmitter</li> <li>1 x HDMI Over CAT6 Receiver</li> <li>1 x Universal Power Adapter (NA/JP, EU, UK, ANZ)</li> <li>1 x IR Blaster</li> <li>1 x IR Receiver</li> <li>2 x Mounting Brackets</li> <li>8 x Rubber Feet</li> <li>1 x Quick-Start Guide</li> </ul>
Country of OriginTaiwan
Packaged Quantity1 Kit
Transmitter Depth4"
Transmitter Width3"
Transmitter Height1"
Media Type SupportedTwisted Pair
Number of HDMI Inputs1
Number of HDMI Outputs1
Connectivity TechnologyWired
Environmental ComplianceWaste Electrical and Electronic Equipment Directive (WEEE)
Environmentally FriendlyYes
Manufacturer Part NumberST121HDBT20L
Maximum Video Resolution4096 x 2160
Maximum Operating Distance328.08 ft
Twisted Pair Cable StandardCategory 6
Manufacturer Website Addresshttp://www.startech.com
Receiver Weight (Approximate)3.88 oz
Number of Network (RJ-45) Ports2
Transmitter Weight (Approximate)3.88 oz
Number of Input Devices Supported1
Number of Output Devices Supported1
