STARTECH.COM

VGA RACKMOUNT KVM CONSOLE INTEGRATED LCD MONITOR KVM SWITCH

SKU: 5VH766VPN: RKCONS1701

VGA RACKMOUNT KVM CONSOLE INTEGRATED LCD MONITOR KVM SWITCH

Key Features

  • FLEXIBLE DESIGN: This rackmount KVM console drawer works with all KVM switch brands and models that supports VGA and USB interfaces and conveniently slides into the server rack when not in use
  • VERSATILE INTERFACES: Rack mount monitor w/ 17" Active Matrix TFT 1280 x 1024 LCD| 1U height | 99 key full keyboard with numeric keypad + Trackpad | Supports VGA and USB | Integrated Power Supply
  • MAX DURABILITY: Features durable steel housing design and rails that withstand frequent use, rated to work in environments from 0 to 40 deg. C and a 50,000 hour MTBF
  • TESTED AND PROVEN: Our KVM consoles are backed by a 2 year warranty with 24/5 by multi-lingual tech support based in North America with free technical support for the life of the product
  • KVM Collection: Can be purchased with integrated 8-port (RKCONS1708K) or 16-port (RKCONS1716K) KVM or use with StarTech.com enterprise KVM switches: SV831DUSB, SV831DUSBUK, SV1631DUSBU, SV1631DUSBUK.
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

Providing centralized control of your PC, server, or KVM switch, this single-port rackmount KVM console gives you easy access to your connected system. With a minimal footprint, it mounts in a server rack or cabinet using only 1U of rack space. An All-Inclusive Solution The 1U rackmount console features a built-in keyboard, a touchpad for intuitive control, and a 17-inch LCD display that supports resolutions up to 1280x1024. This single-port KVM console includes everything you need to set up right out of the box: 1 VGA KVM Cable Mounting Rails M5 Cage Nuts and Screws Simple System Integration The rack console features a single-port KVM module, which can be connected directly to a server or PC, or to a KVM switch for access to multiple systems. The KVM module offers the flexibility you need for easily integrating the console into your existing server infrastructure. StarTech.com Rack Consoles Rack consoles provide convenient, rack-mounted control options for single servers or entire server rooms. KVM consoles include LCD display, keyboard, and trackpad, all sliding into 1U of rack space. RKCONS1701 is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Tech Specs

VGA RACKMOUNT KVM CONSOLE INTEGRATED LCD MONITOR KVM SWITCH specifications
USBYes
VGAYes
Depth18.5"
Width17.6"
Height1.7"
KeyboardYes
Brand NameStarTech.com
KVM SwitchNo
Rack Height1U
Screen ModeSXGA
Screen Size17"
Color FamilyBlack
Show all 41 specs
ManufacturerStarTech.com
Product NameSingle-Port Rackmount KVM Console with 17" Display
Product TypeLCD Rack Console
Input Current1.50 A
Input Voltage230 V AC
Product ColorBlack
WEEE Statementhttps://media.startech.com/cms/pdfs/rkcons1701_weee.pdf
Package Contents<ul> <li>Single-Port Rackmount KVM Console with 17" Display</li> <li>1 x KVM Cable</li> <li>8 x M5 Cage Nuts</li> <li>8 x M5 Screws</li> <li>5 x Regional Power Cords (NA, JP, UK, EU, ANZ)</li> <li>2 x Mounting Rails</li> <li>1 x Quick-start Guide</li> </ul>
Product MaterialSteel
Country of OriginChina
Packaged Quantity1 Each
Power Consumption13 W
Screen Resolution1280 x 1024
Platform SupportedPC
REACH free of SVHCYes
Display Screen TypeLCD
Input Voltage Range100V AC to 240V AC
Number of VGA Ports1
Pointing Device TypeTouchPad
Weight (Approximate)25.90 lb
REACH Declaration URLhttps://media.startech.com/cms/pdfs/rkcons1701_rohs.pdf
EU RoHS Declaration URLhttps://media.startech.com/cms/pdfs/rkcons1701_rohs.pdf
Environmental ComplianceRegistration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Environmentally FriendlyYes
Manufacturer Part NumberRKCONS1701
Environmental CertificationEU RoHS
Manufacturer Website Addresshttp://www.startech.com
Number of Computers Supported1
End of Life Manual AvailabilityYes
