ROCSTOR

USB4 DOCKING STATION RD14 USB4 40G PORTABLE DOCT 8K30H

SKU: NJ2060VPN: Y10P025-S1

USB4 DOCKING STATION RD14 USB4 40G PORTABLE DOCT 8K30H

Key Features

  • Ultra-Fast Data Transfer: USB4 achieves up to 40Gbps for high-speed data and video transfer.
  • Advanced Video Output: Type-C Interface supports up to 8K/30Hz video output and 10G data transmission.
  • Dual DisplayPort: Each port supports up to 8K/30Hz. Simultaneous Dual Output: Capable of dual 4K/60Hz output for enhanced display capabilities.
  • High-Speed Connectivity: RJ45 Ethernet Port: Supports 10M/100M/1000M/2.5G bandwidth for versatile networking.
  • Power Efficiency: Self-Powered. Comes with a 21V 134W DC power supply. Intelligent Power Allocation: Ensures efficient energy distribution across devices.
  • Operating System Support: Compatible with Windows 10 or above and macOS 11 or above.
  • Warranty: Rocstor 3-Year Limited Warranty
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

The Rocstor Premium RD14 USB4 40G Portable Dock delivers unmatched efficiency and versatility for I/O solutions, boasting speeds up to 40Gb/s for seamless data and video transfer. This innovative dock allows for the connection of USB4 devices across six cascading levels, making it a perfect choice for high-performance setups. The Type-C interface supports a remarkable 8K/30Hz video output and facilitates swift 10G data transmission, ensuring optimal performance for all your connectivity needs.

With dual video ports, the dock allows you to connect two displays simultaneously, each supporting dual 4K/60Hz output, making it ideal for multitasking on TBT4/USB4 Windows PC setups. The RJ45 port offers a maximum bandwidth of 2.5G, ensuring fast and reliable networking capabilities. Additionally, the USB ports provide rapid 10G data transmission, while the intelligent power allocation feature optimizes energy distribution based on connected device power consumption, leveraging external power supply efficiently.

Engineered for compatibility with USB4 and Thunderbolt hosts, this dock is designed to meet the demands of modern computing environments. Its slim, compact aluminum design not only enhances durability but also adds a touch of sophistication to any workspace. Experience the pinnacle of connectivity solutions with Rocstor's Premium RD14 dock, perfect for Windows 10 and above, and macOS 11 and above. Backed by Rocstor 3-year limited warranty and lifetime free technical support.

Tech Specs

USB4 DOCKING STATION RD14 USB4 40G PORTABLE DOCT 8K30H specifications
Width3.10"
Height0.80"
Length7.4"
FeaturesCompact
Brand NameRocstor
USB Type-AYes
USB Type-CYes
DisplayPortYes
Form FactorPortable
Cable Length3.28 ft
Color FamilySilver
ManufacturerRocstor
Show all 53 specs
Product LinePremium
Product NamePremium RD14 USB4 40G Portable Dock
Product TypeDocking Station
Compatibility<p><strong>Compatible Products:</strong></p><ul><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>Chromebook</li><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>Dell XPS Laptops</li><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>Apple MacBook</li><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>Microsoft Surface Tablet</li><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>Microsoft Surface Notebook</li><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>USB-C Laptops</li><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>USB-C Tablets</li><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>USB4 Laptops</li><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>Thunderbolt 3 Laptops</li><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>Thunderbolt 4 Laptops</li></ul>
Product ColorAluminum Silver
Product ModelRD14
Host InterfaceUSB4
Network (RJ-45)Yes
Device SupportedDesktop PC
Limited Warranty3 Year
Package Contents<ul><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>Premium RD14 USB4 40G Portable Dock</li><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>1 x User Manual </li><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>1 x 134W AC Power Adapter</li><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>1 x USB4 Cable(1m)</li></ul>
Country of OriginVietnam
Packaged Quantity1
Power Source TypePower Adapter
USB Type-C Detail1 x USB 3.2 Type-C Gen2, 1 x USB-C (8K/10G)
Security Slot TypeKensington Security Slot
USB Power Delivery100W
Brand CompatibilityMicrosoft
Charging CapabilityYes
DisplayPort Version1.4
Ethernet Technology2.5 Gigabit Ethernet
Management FeaturesWake-on-LAN
Weight (Approximate)11.70 oz
Number of RJ-45 Ports1
Screen Mode Supported4K @30Hz
Supported Resolutions3840 x 2160
Connectivity TechnologyWired
Number of USB 2.0 Ports1
Environmental ComplianceWaste Electrical and Electronic Equipment Directive (WEEE)
Kensington Security SlotYes
Manufacturer Part NumberY10P025-S1
Total Number of USB Ports5
Maximum Data Transfer Rate5 GB/s
Number of USB Type-A Ports3
Number of USB Type-C Ports2
Operating System SupportedmacOS 14
Manufacturer Website Addresshttp://www.rocstor.com
Maximum Power Supply Wattage134 W
Number of Displays Supported2
Number of DisplayPort Outputs2
Number of USB 3.2 Gen 2 Type-A Ports2
