SYMMETRA LX 8KVA SCALABLE 16KVA N+1 RACK-MOUNT 220/230/240V
SKU: 9CB135VPN: SYA8K16RMI
SYMMETRA LX 8KVA SCALABLE 16KVA N+1 RACK-MOUNT 220/230/240V
Key Features
- Removable input/output wiring tray - Allows quick and easy installation and maintenance of the UPS.
Request a Quote on This Product
Adding to inquiry lets you bundle multiple products into a single quote request.
Overview
Engineered to deliver the highest level of business continuity possible, the Symmetra LX 8kVA Scalable to 16kVA N+1 Rack-mountable uses a modular, redundant architecture that can scale power and run-time as demand increases or when higher levels of availability are required. Advancements in this next generation design greatly decrease foot print or U-space needed in an equipment rack, increase speed and ease of deployment and reduce repair time.
Tech Specs
| Depth | 27" |
|---|---|
| Width | 19" |
| Height | 33" |
| Brand Name | APC by Schneider Electric |
| Form Factor | Rack-mountable |
| Rack Height | 19U |
| Color Family | Dual Color |
| Manufacturer | Schneider Electric SA |
| Product Line | Symmetra |
| Product Name | Symmetra LX 8kVA Scalable to 16kVA N+1 Rack-mountable UPS |
| Product Type | Double Conversion Online UPS |
| Bypass Switch | Automatic |
Show all 41 specsShow fewer
| Modular Slots | 1 x SmartSlot |
|---|---|
| Product Color | Silver |
| Waveform Type | Sine Wave |
| Output Voltage | 230 V AC |
| Product Family | Symmetra LX |
| Product Series | LX |
| Input Frequency | 65 Hz |
| Receptacle Type | Hard Wire 3-wire |
| Output Frequency | 60 Hz |
| Package Contents | <li>Symmetra LX 8kVA Scalable to 16kVA N+1 Rack-mountable UPS </li><li>CD with software</li><li>Documentation CD</li><li>Installation guide</li><li>User manual</li><li>Web/SNMP management card</li> |
| Battery Chemistry | Lead Acid |
| Receptacle Detail | 8 x IEC 320-C13 |
| Load Capacity (VA) | 8000 VA |
| Network Management | SNMP Manageable |
| Emergency Power OFF | Yes |
| Overload Protection | Yes |
| Plug/Connector Type | Hard Wire 5-wire |
| Thermal Dissipation | 1086.41 W |
| Weight (Approximate) | 437 lb |
| Additional Information | <ul><li>Automatic restart of loads after UPS shutdown</li><li>Audible and visible alarms prioritized by severity</li><li>InfraStruXure Manager Compatible</li><li>Plug-and-Play external batteries</li><li>Configurable for 220, 230 or 240 nominal output voltage</li></ul> |
| Battery Characteristics | Spill-proof/Maintenance-free |
| Environmentally Friendly | Yes |
| Manufacturer Part Number | SYA8K16RMI |
| Certifications & Standards | <ul><li>C-tick</li><li>CE</li><li>EN 50091-1</li><li>EN 50091-2</li><li>EN 55022 Class A</li><li>EN 55024</li><li>EN 60950</li><li>GOST</li><li>IEC 60950</li><li>VDE</li></ul> |
| Backup/Run Time (Full Load) | 7.50 Minute |
| Backup/Run Time (Half Load) | 20.20 Minute |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Maximum Operating Temperature | 104°F (40°C) |
| Number of Battery & Surge Outlets | 19 |
