APC SCHNEIDER ELECTRIC IT USA

RACK PDU 9000 SWITCHED ZEROU 30A 200/208V 21 C13 3 C19

SKU: 8RP378VPN: APDU9941

RACK PDU 9000 SWITCHED ZEROU 30A 200/208V 21 C13 3 C19

Key Features

  • Rackmount PDU
  • Rack Power Distribution
  • APC rack PDU
  • Rack PDU
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

The APC Switched Rack PDU distributes reliable power within a rack through a single input and multiple output receptacles The APDU9941 offers advanced load management combined with remote on/off switching control of individual outlets for power cycling, delayed power sequencing, and outlet use management The 0U PDU includes a NEMA L6-30P input plug with 3 05m (10 ft) cord, (21) IEC 60320 C13/C15 and (3) IEC 60320 C19/C21 hybrid outlet receptacles The hybrid outlets allow 60°C operating temperature at full load, are compatible with standard C14 and C20 power cords, and are future-proofed for new C16 and C21 power cords required for higher temperature rated devices The Network Management Card provides enhanced cybersecurity with secured interfaces and modified password policy The rack PDU integrates with EcoStruxure IT through Network Management Card and can be accessed, configured, and managed remotely via Web, SNMP and Command Line Interface Color user-interactive LCD interface details current, real power, voltage, and energy measurements for local user access The outlet level control allows power on/off functionality for power recycling/reboot of remote equipment and restricts unauthorized use of individual outlets The Switched Rack PDU includes a temperature/humidity sensor port, locking IEC outlets when used with locking power cords, low-profile circuit breakers and USB port for local Firmware updates The rack PDU supports daisy-chain of up to 32 PDUs on a single IP address, thereby reducing networking cost The rack PDU comes with a standard three-year warranty

Tech Specs

RACK PDU 9000 SWITCHED ZEROU 30A 200/208V 21 C13 3 C19 specifications
Depth1.8"
Width2.2"
Height72"
PDU TypeSwitched
PlacementSide
Brand NameAPC by Schneider Electric
Management<ul> <li>Web</li> <li>SNMP</li> <li>Telnet</li> </ul>
Mount TypeRack-mountable
Cord Length9.84 ft
Form FactorTower
Rack Height0U
ManufacturerSchneider Electric SA
Show all 46 specs
Product NameNetShelter 9000 24-Outlet PDU
Product TypePDU
Input Current30 A
Input Voltage200 V
Output Voltage208 V AC
Product Family9000
Product Series9000
WEEE StatementThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Network (RJ-45)Yes
Protection TypeOverload Protection
Receptacle TypeIEC 60320 C13/C15
Package Contents<li>NetShelter 9000 24-Outlet PDU </li><li>Installation guide</li><li>Rack mounting brackets</li><li>Safety guide</li>
Country of OriginIndia
Power Rating (VA)4992 VA
Receptacle Detail3 x IEC 60320 C19/C21
For Country/RegionUnited States
REACH free of SVHCNo
Input Voltage Range200 V AC - 240 V AC
Mounting PreferenceNo Preference
Plug/Connector TypeNEMA L6-30P
Power Rating (Watt)5000 W
Mounting OrientationVertical
Weight (Approximate)18.74 lb
REACH Declaration URLhttps://download.schneider-electric.com/files?p_Doc_Ref=APDU9941_REACH_DECLARATION&p_enDocType=Declaration+of+Conformity+(Sustainability)
EU RoHS Declaration URLhttps://download.schneider-electric.com/files?p_Doc_Ref=APDU9941_ROHS_DECLARATION&p_enDocType=Declaration+of+Conformity+(Sustainability)
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
Environmentally FriendlyYes
Manufacturer Part NumberAPDU9941
Product Take Back ProgramNo
Certifications & StandardscUL Listed|FCC part 15 class A|PSE
RoHS Exemption Informationhttps://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=APDU9941_ROHS_DECLARATION&p_FileName=APDU9941KIT_ROHS_DECLARATION_US.pdf
Manufacturer Website Addresshttp://www.schneider-electric.com
End of Life Manual Availabilityhttps://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612033_EN
Environmental Profile Availabilityhttps://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612033EN
