PLUGABLE UD-ULTC4K USB-C 4K TRIPLE DISPLAY DOCK W/ PD
PLUGABLE UD-ULTC4K USB-C 4K TRIPLE DISPLAY DOCK W/ PD
Key Features
- All in One USB C Docking Station with Power - Named "Best Docking Station 2025" by How-To Geek, this multi-monitor station features 13 powerful ports. It includes USB-C with 100W charging, 4x USB-A, Ethernet, an SD card reader, and more - all through a single 10Gbps USB-C connection. It is the definitive complete docking station setup for busy professionals.
- Triple 4K: Extend your view with this triple monitor docking station featuring 3x HDMI and 3x DisplayPort outputs. Mix and match for ultimate flexibility - drive three 4K monitors at 60Hz on Thunderbolt, USB4, or Alt Mode laptops. No extra dongles or converters required.
- 100W Power Delivery: Power your laptop with up to 100W (96W certified) directly through the DisplayLink docking station, so you can leave your laptop power adapter in your travel bag.
- Compatibility: This USB-C dock is compatible with Windows 10 or later, macOS 11+, and ChromeOS (100.x or later) systems with Thunderbolt, USB4, or USB-C. Requires installation of DisplayLink Drivers, refer to the setup guide video in image gallery. HDCP (streaming services) not supported.
- Connection Options: Triple display docking station lets you connect your phone or other devices with 1x USB-C (10Gbps, 20W PD), and keep expanding with 4x USB 3.0 (5Gbps), an SD card reader, Gigabit Ethernet, and audio in and out ports.
Adding to inquiry lets you bundle multiple products into a single quote request.
Overview
The Plugable UD-ULTC4K is a USB-C docking station designed for business and mixed-device environments. It supports up to three external displays through a combination of DisplayPort and HDMI connections, with up to 4K 60Hz resolution depending on host system capabilities. Named "Best Docking Station 2025" by How-To Geek. The dock includes 3 DisplayPort outputs and 3 HDMI outputs, allowing flexible monitor connections without requiring adapters for different display types. In addition to display connectivity, the dock features a front-facing USB-C port with up to 10Gbps data transfer and 20W charging for compatible accessories, 4 USB 3.0 ports with up to 5Gbps transfer speeds, an SD card reader, Gigabit Ethernet, and separate 3.5mm audio input and output ports. The host connection supports up to 100W USB-C Power Delivery, with 96W certified for supported laptops. The replaceable USB-C host cable can help simplify setup and maintenance in office deployments. Compatible with supported Windows, macOS, and ChromeOS systems. DisplayLink drivers are required for DisplayLink-based video outputs. HDCP is not supported, so protected content playback from some streaming services may be limited. Port configuration includes 1 USB-C host connection with up to 100W Power Delivery, 2 DisplayPort 1.2 outputs using DisplayLink, 1 DisplayPort 1.2 output using Alt Mode, 2 HDMI 2.0 outputs using DisplayLink, 1 HDMI 2.0 output using Alt Mode, 4 USB 3.0 ports, 1 USB-C port with 10Gbps and 20W charging, 1 SD card reader, 1 Gigabit Ethernet port, and 1 audio input.
Tech Specs
| HDMI | Yes |
|---|---|
| Width | 2.90" |
| Height | 7.90" |
| Brand Name | Plugable |
| Microphone | Yes |
| USB Type-A | Yes |
| USB Type-C | Yes |
| DisplayPort | Yes |
| HDMI Version | 1.4 |
| Manufacturer | Plugable Technologies |
| Product Name | USB-C Triple 4K Display Docking Station |
| Product Type | Docking Station |
Show all 43 specsShow fewer
| Audio Line In | Yes |
|---|---|
| Compatibility | Thunderbolt, USB4, or Alt Mode laptops |
| Product Model | UD-ULTC4K |
| Audio Line Out | Yes |
| Host Interface | USB Type C |
| Network (RJ-45) | Yes |
| Device Supported | Notebook |
| Limited Warranty | 2 Year |
| Package Contents | <ul> <li>USB-C Triple 4K Display Docking Station</li> <li>1 x USB-C to USB-C Cable</li> <li>1 x 100W Power Adapter</li> </ul> |
| Country of Origin | Taiwan |
| Packaged Quantity | 1 |
| USB Type-C Detail | 1 x USB-C Front USB 3.0 (5Gbps) |
| DisplayPort Version | 1.2 |
| Ethernet Technology | Gigabit Ethernet |
| Weight (Approximate) | 1.37 lb |
| Number of RJ-45 Ports | 1 |
| Screen Mode Supported | 4K |
| Supported Resolutions | 1280 x 720 |
| Additional Information | <ul> <li>Cable | USB-C to USB-C</li> <li>Video Output 1 | HDMI (White, VESA Alternate Mode)</li> <li>Video Output 2 | DisplayPort++ (Black, DisplayLink)</li> <li>Video Output 3 | DisplayPort++ (Black, DisplayLink)</li> <li>USB Ports (Front) | 1 x USB 3.0 Type-A, 1 x USB 3.0 Type-C</li> <li>USB Ports (Rear) | 3 x USB 3.0 Type-A, 1 x USB 3.0 Type-C to Host</li> <li>Ethernet | 1 x Gigabit Ethernet Port</li> <li>Audio | 1 x 3.5mm Headphone Out, 1 x 3.5mm Audio In</li> <li>Power Adapter | In: AC 120-240V, 50/60Hz, Out: DC100W (20V/5A)</li> <li>Power Delivery | USB Power Delivery Compliant (PD 2.0)</li> </ul> |
| Number of HDMI Outputs | 1 |
| Connectivity Technology | Wired |
| Number of USB 3.0 Ports | 5 |
| Manufacturer Part Number | UD-ULTC4K |
| Total Number of USB Ports | 5 |
| Number of USB Type-A Ports | 4 |
| Number of USB Type-C Ports | 1 |
| Operating System Supported | Windows |
| Manufacturer Website Address | http://www.plugable.com |
| Maximum Power Supply Wattage | 60 W |
| Number of Displays Supported | 3 |
| Number of DisplayPort Outputs | 2 |
