MSA AND TAA COMP RUGGED XCVR 40KM 25G-BX LC 1330NMTX/1270NMRX

SKU: 9DB056VPN: SFP-25GB-BX40-D-I-AO

MSA AND TAA COMP RUGGED XCVR 40KM 25G-BX LC 1330NMTX/1270NMRX

Key Features

  • Electrical interface specifications per SFF-8431
  • Management interface specifications per SFF-8432 and SFF-8472
  • SFP28 MSA package with Single LC receptacle
  • DFB Laser, APD photo-detector
  • Up to 25.78G bi-directional data links
  • Single +3.3V power supply
  • Class 1 laser safety certified
  • Operating case temperature: -40o C to +85o C
  • Up to 40km on 9/125µm SMF
  • RoHS Compliant
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

This MSA compliant SFP28 transceiver provides 25GBase-BX throughput up to 40km over single-mode fiber (SMF) using a wavelength of 1310nmTx/1270nmRx via an LC connector. This bidirectional unit must be used with another transceiver or network appliance of complementing wavelengths. It can operate at temperatures between -40 and 85C. It is built to MSA standards and is uniquely serialized and data-traffic and application tested to ensure that they will integrate into your network seamlessly. Digital optical monitoring (DOM) support is also present to allow access to real-time operating parameters. This transceiver is Trade Agreements Act (TAA) compliant. We stand behind the quality of our products and proudly offer a limited lifetime warranty.

Tech Specs

MSA AND TAA COMP RUGGED XCVR 40KM 25G-BX LC 1330NMTX/1270NMRX specifications
Depth2.2"
Width0.6"
Height0.4"
FeaturesBi-Directional (BiDi)
Brand NameAddOn
ManufacturerAddOn
Product NameSFP28 Module
Product TypeSFP28
CompatibilityMSA Compliant
TAA CompliantYes
Connector TypeLC
Application/UsageOptical Network
Show all 30 specs
Country of OriginUnited States/United Kingdom
Packaged Quantity1
Network Technology25GBase-BX
Ethernet Technology25 Gigabit Ethernet
Fiber Mode SupportedSingle-mode
Media Type SupportedOptical Fiber
Weight (Approximate)0.20 lb
Total Number of Ports1
Environmental ComplianceRestriction of Hazardous Substances (RoHS) 2
Environmentally FriendlyYes
Interfaces/Ports DetailsLC 25GBase-BX Network
Manufacturer Part NumberSFP-25GB-BX40-D-I-AO
Maximum Data Transfer Rate25 Gbit/s
Maximum Distance Supported40 km
Fiber Optic Cable Wavelength1310 nm
Manufacturer Website Addresshttp://www.addoncomputer.com
Maximum Operating Temperature185°F (85°C)
Minimum Operating Temperature-40°F (-40°C)
