HDMI 2.0 OVER IP MATRIX AND

SKU: 8JX768VPN: CE-H25311-S1

Limited Stock

$559.99$255.83

Actual pricing depends on volume, configuration, and current promotions. Reach out and we'll put together a real quote — often below this number.

Key Features

Video Extender Receiver is all you need for dependable and productive audio/video transmission
HDMI in allows convenient transfer of content and data to video extender receiver to ensure maximum dependability
HDMI out enables you to transfer data from your devices to video extender receiver with added efficiency
Connect your video extender receiver to your PC to supply power and conveniently transfer the photos and videos for editing and sharing on the social media
Twisted pair media type is very easy to connect and can carry both analog and digital data at the same time for maximum connection efficiency
1 input devices supported to better accommodate your specific requirements
1 output devices supported for maximum feasibility and usage convenience
394 ft maximum operating distance to allow efficient coverage and maximum usability
4K graphics mode provides optimal video output with remarkable picture clarity

Adding to inquiry lets you bundle multiple products into a single quote request.

Extends HDMI audio/video signals through IP networks up to 394ft (120m), matrix and video wall configurable on the fly

HDMI 2.0a and HDCP 2.2 compliant
Supports HDMI input up to 4Kx2K@60Hz YUV 4:4:4 8bit, HDMI output up to 4Kx2K@30Hz
Flexible and scalable video broadcasting by IGMP Gigabit Ethernet Router/Switch
Supports 4K signals including High Dynamic Range (HDR), PoE, Bi-directional IR path, and Video Wall. Due to the video compression, some distortion may occur in HDR mode
Supports One-to-one, One-to-many, and Many-to-many broadcasting architecture
Easy DIP switch matching for multi-casting group configuration
Supports full frequency IR signal from 20KHz to 60KHz
Full Duplex RS-232 control up to 115,200 bps
Supports 180° and 270° clockwise image rotation
Designed to work with HDMI 2.0 Video Wall Over IP Multicast System - Transmitter, part # CE-H25211-S1 sold separately, and HDMI 2.0 Video Wall Over IP Multicast System - Controller, part # CE-H25411-S1 sold separately

HDMI 2.0 OVER IP MATRIX AND specifications
USB	Yes
HDMI In	Yes
HDMI Out	Yes
Brand Name	SIIG
Manufacturer	SIIG, Inc
Product Name	HDMI 2.0 Over IP Matrix and Video Wall - Receiver
Product Type	Video Extender Receiver
Product Color	Black
TAA Compliant	Yes
Graphics Modes	4K
Receiver Depth	7.09"
Receiver Width	4"

Show all 31 specs

Network (RJ-45)	Yes
Receiver Height	1.13"
Package Contents	<ul> <li>HDMI 2.0 Over IP Matrix and Video Wall - Receiver </li> <li>Power Adapter 5V/2A</li> <li>1 x IR Receiver Cable</li> <li>2 x Screw Kit</li> <li>Insert Card</li> <li>User Manual</li> </ul>
Country of Origin	Taiwan
Number of USB Ports	2
Media Type Supported	Twisted Pair
Number of HDMI Inputs	1
Number of HDMI Outputs	1
Connectivity Technology	Wired
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Environmentally Friendly	Yes
Manufacturer Part Number	CE-H25311-S1
Maximum Operating Distance	394 ft
Twisted Pair Cable Standard	Category 5e
Manufacturer Website Address	http://www.siig.com
Receiver Weight (Approximate)	1.07 lb
Number of Network (RJ-45) Ports	1
Number of Input Devices Supported	1
Number of Output Devices Supported	1
