BLACK BOX CORPORATION

EMERALD 4K DISPLAY PORT VUSB AUDIO VM TX

SKU: 5HF428VPN: EMD4000T

EMERALD 4K DISPLAY PORT VUSB AUDIO VM TX

Key Features

  • Fault Tolerant Architecture
  • Best in Class Virtual Machine Integration
  • Complete BYOD Solution
  • Unified Platform Architecture
  • Enterprise Level Security
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

A unified control platform for all your mission-critical systems What Is Emerald? Emerald is a control platform that lets operators access and control multiple computers virtual machines and web-based systems from a single workspace. It removes the need for multiple keyboards screens and desks by bringing everything into one unified operating environment. Fault-Tolerant Architecture Emerald is designed to stay online even when components fail. Redundant network paths and resilient system design ensure continuous access during outages maintenance or unexpected disruptions. Best-in-Class VM Integration Emerald connects directly to virtual machines without extra hardware. Operators can access physical and virtual systems from the same interface using the same keyboard and mouse with support for multi-user collaboration. Complete BYOD Solution Emerald supports secure access from personal laptops using native Windows and macOS applications. This enables flexible hybrid and remote workflows without compromising performance or control. Unified Platform Architecture Emerald provides one consistent platform for physical systems virtual machines and web applications. This simplifies operations reduces training time and minimizes operator fatigue. Enterprise-Level Security Emerald uses encrypted communications centralized access control and policy management to protect systems and data while maintaining fast intuitive access for operators. Centralized Command and Control Emerald allows operators to monitor and control multiple systems at once from a single workstation. Industry-first UltraStream(tm) Technology delivers multiple simultaneous 4K streams over 1GbE and 10GbE infrastructures. Ideal for mixed HD and 4K users. Why It Matters Emerald is designed around how people actually work in control rooms. By reducing screen clutter simplifying access and keeping systems available under pressure Emerald helps teams stay focused coordinated and effective no matter how complex the environment becomes.

Tech Specs

EMERALD 4K DISPLAY PORT VUSB AUDIO VM TX specifications
USBYes
Frequency60 Hz
HeadphoneYes
Brand NameEmerald®
MicrophoneYes
Device TypeKVM Extender
DisplayPortYes
Graphic Mode4K
ManufacturerBlack Box Corporation
Product Name4K KVM-over-IP Extender - DisplayPort, Single-Monitor, V-USB 2.0, Audio
Product TypeKVM Extender Transmitter
Input Voltage120 V AC
Show all 38 specs
Product ModelEMD4000T
TAA CompliantYes
KVM TechnologyDigital
Network (RJ-45)Yes
Package Contents<ul><li>4K KVM-over-IP Extender - DisplayPort, Single-Monitor, V-USB 2.0, Audio</li><li>1 x USB Type-A to B Cable, 6-ft. (1.8-m)</li><li>1 x DisplayPort Male to Male Cable, 6-ft. (1.8-m)</li><li>2 x 3.5mm Audio Cables, 5-ft. (1.5-m)</li><li>1 x 12-VDC Power Supply and Power Clips</li></ul>
Country of OriginIreland
Packaged Quantity1
Transmitter Depth7.40"
Transmitter Width8.50"
Platform SupportedLinux
Transmitter Height1.50"
Data Link ProtocolsTCP/IP
Input Voltage Range100V AC to 240V AC
Number of USB Ports1
Additional Information<li>Humidity: 5 to 95%, non-condensing</li><li> Operating Temperature: 32°F to 104°F (0°C to 40°C)</li><li> Storage Temperature: -4° to 140°F (-20° to 60° C)</li><li> Operating Systems Supported: Microsoft Windows® 10/11, Server OS, LInux®, and Mac OS</li><li> Distance Supported: Distance between TX and RX: 328 ft (100 m) over CATx</li><li> Compatibility: Boxilla, Emerald ecosystem</li> <p><b>Compatibility Note:</b></p> <li>Emerald4K_Firmware_v6.0 firmware is compatible with other 6.0 endpoints.</li><li> The EMD4000R can connect to the EMD4000T, EMD200DV-T, Emerald SE/PE Transmitters using 6.x firmware or higher, but not to an Emerald SE/PE Receiver to an EMD4000T.</li><li> Firmware 6.0 is not compatible with Firmware 1.4.</li><li> EMD4000T cannot be accessed by any version of RemoteApp to date.</li> <p><b>Connectors</b></p> <li>Video Interface: (1) DisplayPort Input</li><li> USB Ports: (1) USB Type-B</li><li> Audio I/O: (2) 3.5 mm jacks; Audio, mic</li><li> Network Interface: (1) RJ-45 (1GbE)</li><li> SFP+ (Fiber Support): (2) SFP+ cages</li><li> Serial Support: (1) DB9 serial</li>
Connectivity TechnologyWired
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
Manufacturer Part NumberEMD4000T
Maximum Video Resolution4096 x 2160
Certifications & Standards<ul><li>Unit: Directive 2014/30/EU, CE, FCC, ICES, UKCA, 2011/65/EU, 2015/863/EU, Reach, TSCA, CB</li><li>Power Supply: Directive 2014/35/EU, EN 62368-1:2014, UL, cUL, GS, PSE, BSMI, CB, RCM, BIS</li></ul>
Maximum Operating Distance328.08 ft
Manufacturer Website Addresshttp://www.blackbox.com
Number of Computers Supported1
Additional Warranty Information<p>2 Years Double Diamond™ Warranty (Standard)</p>
Number of Network (RJ-45) Ports1
Transmitter Weight (Approximate)2.50 lb
