DB9 RS232 SERIAL OVER CAT5 EXTENDER - SERIAL PORT EXTENDER
SKU: GV9498VPN: RS232EXTC1
DB9 RS232 SERIAL OVER CAT5 EXTENDER - SERIAL PORT EXTENDER
Key Features
- Extend RS232 up to 1000m / 3300ft
- Data transfer rates of up to 230Kbps
- Compatible with all RS232 communications
- Employ existing Cat 5, 5e, 6 or better Ethernet infrastructure to remotely connect serial devices
- Supports full-duplex data communication
- Compact design
- No driver software required for easy Plug-and-Play installation
Request a Quote on This Product
Adding to inquiry lets you bundle multiple products into a single quote request.
Overview
The RS232EXTC1 Serial over Cat 5 Extender allows you to increase the distance of your RS232 Serial connection by up to 1000 meters (3300 feet), giving you the ability to connect serial peripheral devices up to a kilometer away from your system - an incredible 65x greater than normal RS232 serial cable length restrictions would permit. The Extender is a cost-effective serial extension solution and completely hardware-based, eliminating the need to install additional software, allowing for a completely plug and play installation. The hardware can be setup in minutes, using existing or new Cat 5 or better Ethernet cabling. Perfect for use in industrial monitoring and control, POS, security, medical, and traffic flow applications, the RS232 Serial over Cat 5 extender maintains the RS232 standard with support for data transfer rates of up to 230 Kbps. Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Tech Specs
| Width | 1.3" |
|---|---|
| Height | 0.9" |
| Length | 3.6" |
| Brand Name | StarTech.com |
| Color Family | Silver |
| Manufacturer | StarTech.com |
| Product Name | Serial DB9 RS232 Extender over Cat 5 - Up to 3300 ft (1000 meters) |
| Product Type | Serial Extender |
| Input Voltage | 230 V AC |
| Product Color | Silver |
| TAA Compliant | Yes |
| Network (RJ-45) | Yes |
Show all 24 specsShow fewer
| Package Contents | <ul> <li>RS232 Extender Local Unit</li> <li>RS232 Extender Remote Unit</li> <li>20cm Null Modem cable (DB-9 Male to Male)</li> <li>Power Adapter</li> <li>User Manual</li> </ul> |
|---|---|
| Product Material | Steel |
| Country of Origin | Taiwan |
| Packaged Quantity | 1 Each |
| Additional Information | <ul><li>Enables use of separate control rooms away from harsh environmental conditions where serial devices may be located</li><li>Provides you with flexibility when choosing the location of your serial peripherals by dramatically increasing the maximum RS232 serial cable length</li><li>Pure hardware design, no software or drivers required ensuring a simple plug and play installation</li></ul> |
| Maximum Extended Range | 3280.84 ft |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Environmentally Friendly | Yes |
| Manufacturer Part Number | RS232EXTC1 |
| Maximum Data Transfer Rate | 230 kB/s |
| Manufacturer Website Address | http://www.startech.com |
| Number of Network (RJ-45) Ports | 2 |
