CYBEX 4PORT SC DVI SECURE KVM SW DUAL DISP PP4.0
CYBEX 4PORT SC DVI SECURE KVM SW DUAL DISP PP4.0
Key Features
- NIAP 4.0 Certified: Security: Secure 8-port KVM with always-on anti-tampering, NIAP 4.0 certified.
- Enhanced Situational Awareness: Equipped with customizable indicators that display active channels.
- Versatile Video Support: Supports DP, HDMI, and DVI-I up to 3840 x 2160 resolution for HD visuals.
- Peripheral Isolation: Combines keyboard, mouse, and display into one setup for a clutter-free space.
- Freeze Audio Channel: Locks the audio channel to a computer for an uninterrupted audio output.
Adding to inquiry lets you bundle multiple products into a single quote request.
Overview
The Vertiv Avocent Cybex SC940DVI-400 secure desktop KVM switch provides secure connectivity across multiple resources. It lets users switch between computers with different security levels while preventing data leaks. Designed for security-conscious organizations, the SC940DVI-400 isolates each connected system, enforcing unidirectional data flow to safeguard sensitive information. It supports a maximum resolution of 3840 x 2160 at 30 Hz, delivering crisp, clear visuals. The eight universal video ports (DisplayPort and HDMI) allow easy connection of up to two systems, while a 3.5mm audio jack supports alerts and notifications. Features Cursor Navigation Switching (CNS) that enables seamless control transfer between computers by holding the left CTRL key while moving the cursor across screen borders. Certified to the latest NIAP Common Criteria Protection Profile for Peripheral Sharing Switch (version 4.0), this unit also features active intrusion detection and tamper-evident labels.
Tech Specs
| DVI | Yes |
|---|---|
| USB | Yes |
| VGA | No |
| HDMI | Yes |
| Depth | 5" |
| Width | 13.7" |
| Height | 2.2" |
| Features | Intrusion Detection |
| PS/2 Port | Yes |
| Brand Name | Vertiv AVOCENT |
| Device Type | Secure KVM |
| DisplayPort | Yes |
Show all 50 specsShow fewer
| Energy Star | No |
|---|---|
| Form Factor | Desktop |
| Rack Height | 1U |
| Graphic Mode | 4K |
| Manufacturer | Vertiv |
| Product Line | Cybex |
| Product Name | Cybex SC900 Secure Desktop KVM Switch, Dual Head Monitor, 8 Port, Touch Screen Support, NIAP Version 4.0, TAA Compliant (SC940DVI-400) |
| Product Type | KVM Switchbox |
| Input Current | 1.50 A |
| Product Model | SC940 |
| TAA Compliant | Yes |
| KVM Technology | Digital & Analog |
| Product Family | Cybex 900 |
| Product Series | 900 |
| Management Port | No |
| Network (RJ-45) | No |
| Package Contents | <ul><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>Cybex SC900 Secure Desktop KVM Switch, Dual Head Monitor, 8 Port, Touch Screen Support, NIAP Version 4.0, TAA Compliant (SC940DVI-400)</li><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>Power Supply</li></ul> |
| Country of Origin | United States |
| Packaged Quantity | 1 |
| Input Voltage Range | 100VAC-240VAC |
| Number of DVI Ports | 10 |
| Number of USB Ports | 6 |
| Number of VGA Ports | 0 |
| Number of HDMI Ports | 8 |
| Number of PS/2 Ports | 4 |
| Weight (Approximate) | 3.70 lb |
| Number of DisplayPorts | 8 |
| Connectivity Technology | Wired |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Manufacturer Part Number | SC940DVI-400 |
| Maximum Video Resolution | 3840 x 2160 |
| Certifications & Standards | <p>NIAP 4.0 certified</p> |
| Maximum Operating Distance | 10 ft |
| Manufacturer Website Address | http://www.vertiv.com/ |
| Number of Computers Supported | 4 |
| Number of Local Users Supported | 1 |
| Number of Network (RJ-45) Ports | 0 |
| Number of Remote Users Supported | 0 |
