CISCO COMP RUGGED SMF XCVR 40KM TAA 25G-BX LC 1330NMTX/1270NMRX

SKU: 9DB058VPN: SFP-25G-BX-D-40-I-AO

CISCO COMP RUGGED SMF XCVR 40KM TAA 25G-BX LC 1330NMTX/1270NMRX

Key Features

  • Electrical interface specifications per SFF-8431
  • Management interface specifications per SFF-8432 and SFF-8472
  • SFP28 MSA package with Single LC receptacle
  • DFB Laser, APD photo-detector
  • Up to 25.78G bi-directional data links
  • Single +3.3V power supply
  • Class 1 laser safety certified
  • Operating case temperature: -40o C to +85o C
  • Up to 40km on 9/125µm SMF
  • RoHS Compliant
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

This Cisco SFP-25G-BX-D-40-I compatible SFP28 transceiver provides 25GBase-BX throughput up to 40km over single-mode fiber (SMF) using a wavelength of 1310nmTx/1270nmRx via an LC connector. This bidirectional unit must be used with another transceiver or network appliance of complementing wavelengths. It can operate at temperatures between -40 and 85C. It is guaranteed to be 100% compatible with the equivalent Cisco transceiver. This easy to install, hot swappable transceiver has been programmed, uniquely serialized and data-traffic and application tested to ensure that it will initialize and perform identically. Digital optical monitoring (DOM) support is also present to allow access to real-time operating parameters. This transceiver is Trade Agreements Act (TAA) compliant. We stand behind the quality of our products and proudly offer a limited lifetime warranty.

Tech Specs

CISCO COMP RUGGED SMF XCVR 40KM TAA 25G-BX LC 1330NMTX/1270NMRX specifications
Depth2.2"
Width0.6"
Height0.4"
FeaturesDigital Optical Monitoring (DOM)
Brand NameAddOn
Form FactorHot-swappable
ManufacturerAddOn
Product NameCisco SFP28 Module
Product TypeSFP28
CompatibilityMSA Compliant
TAA CompliantYes
Connector TypeLC
Show all 31 specs
Application/UsageData Networking
Country of OriginUnited States/United Kingdom
Packaged Quantity1
Network Technology25GBase-BX
Ethernet Technology25 Gigabit Ethernet
Fiber Mode SupportedSingle-mode
Media Type SupportedOptical Fiber
Weight (Approximate)0.20 lb
Total Number of Ports1
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
Environmentally FriendlyYes
Interfaces/Ports DetailsLC 25GBase-BX Network
Manufacturer Part NumberSFP-25G-BX-D-40-I-AO
Maximum Data Transfer Rate25 Gbit/s
Maximum Distance Supported40 km
Fiber Optic Cable Wavelength1270 nm
Manufacturer Website Addresshttp://www.addoncomputer.com
Maximum Operating Temperature185°F (85°C)
Minimum Operating Temperature-40°F (-40°C)
