ADVANTECH (B+B SMARTWORX)

8FE+2G PORT GIGABIT MANAGED REDUNDANT INDUST SWITCH -40-75 C

SKU: 9V0406VPN: EKI-7710E-2CI-AE

8FE+2G PORT GIGABIT MANAGED REDUNDANT INDUST SWITCH -40-75 C

Key Features

  • 8 Fast Ethernet ports + 2 Gigabit Copper/SFP combo ports
  • SFP socket for Easy and Flexible Fiber Expansion
  • Redundancy: Gigabit X-Ring Pro (ultra high-speed recovery time < 20 ms), RSTP/STP (802.1w/1D)
  • IXM function enables fast deployment
  • Security: 802.1x (Port-Based, MD5/TLS/TTLS/PEAP Encryption), RADIUS
  • Management: SNMP v1/v2c/v3, WEB, Telnet, Standard MIB, Private MIB
  • -40 ~ 75°C wide-range operating temperature (EKI-7710E-2CI)
  • Dual 12~48 V DC power input and 1 relay output
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

EKI-7710E-2C/2CI supports 8 Fast Ethernet ports and 2 Gigabit combo ports. It can provide users abundant ports to connect many devices. Besides, it is embedded with Advantech IXM function, this can benefit users for fast deployment and can dramatically save engineers time and costs. The EKI-7710E series also support NMS to help IT managers with networking maintenance and failure prevention. Finally, the EKI-7710E series is equipped with X-Ring which can achieve ultra high speed recovery time of less than 20 ms to ensure network stability.

Tech Specs

8FE+2G PORT GIGABIT MANAGED REDUNDANT INDUST SWITCH -40-75 C specifications
Depth4.1"
Width2.9"
Height6"
ModularYes
Brand NameAdvantech
ManageableYes
Stack PortNo
Form FactorWall Mountable
Uplink PortNo
ManufacturerAdvantech Co., Ltd
Product Name8FE + 2G Combo Port Managed Ethernet Switch w/ Wide Temp
Product TypeEthernet Switch
Show all 30 specs
Product ModelEKI-7710E-2CI
Product FamilyEKI-7710
Product SeriesEKI-7710
Layer Supported2
Shared SFP SlotYes
Packaged Quantity1
Network Technology10/100Base-TX
Ethernet TechnologyFast Ethernet
Expansion Slot TypeSFP
Number of SFP Slots2
Media Type SupportedOptical Fiber
Weight (Approximate)2.43 lb
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
Environmentally FriendlyYes
Manufacturer Part NumberEKI-7710E-2CI-AE
Port/Expansion Slot Details2 x Gigabit Ethernet Expansion Slot
Manufacturer Website Addresshttp://www.advantech.com
Total Number of Network Ports10
