5GHZ 12DBI OUTDOOR CPE KIT .

5+km transmission Range

OS3 adopts of internal power amplifier and 12dBi directional antenna to provide an efficient way to pick up and maintain a stable signal for a wireless network up to 5km.

Flexible power supply method enable it easy to deployment

OS3 supports 12V 1A Passive PoE and 12V 1A DC power supply option. It helps the engineer to deploy the device flexibly.

TD-MAX--Tenda TDMA proprietary protocol

TD-MAX is Tenda TDMA (Time Division Multiple Access) proprietary protocol to improve performance and capacity for wireless P2MP outdoor application scenarios.

In outdoor enviroment, the CPE use highly directional antennas to connect to the Basestation from distances that can span several kilometers. the CPE can't sense each other, they become "hidden nodes" and cannot coordinate access to the wireless channel. Thus the Basestation experiences frequent collisions from stations transmitting simultaneously. As the network scales, these collisions build up exponentially, increasing latency and lowering throughput.

With TD-MAX, it coordinate all the data transmission and allocates time to active clients to provide greater noise immunity performance when compared to the conventional 802.11 CSMA/CA (Carrier Sense Multiple Access / Collision Avoidance) protocol.

Auto-bridge technology enable it to easy setup

OS3 supports auto-bridge technology, It enables the CPE or basestation in factory default settings to connect to each other automaticaly after the device is powered on. It is very useful for the person who is not familiar with network knowledge, especially for CCTV surveillance transmission application.

Easy to Setup and Manage

OS3 comes with a centralized management software that helps users easily to manage all the devices in the network from a single PC-CPE Assistant.

Professional Outdoor Design

Equipped with IP65 waterproof enclouse and high quality hardware design, OS3 can work in various weather conditions, such as sunshine, rainfall or extremely low/high temperature environment

Multiple Application Scenarios | PtP Connection For CCTV Transmission

One work as AP mode and another work as Station mode to create a long distance wrieless connecton for video surveillance

PtP Connection For internet sharings

One work as AP mode and another work as Station mode to create a long distance wrieless connecton for internet sharing between buildings or neighbors

Wireless Internet Access for Private ISP

Wirelessly connect to Private ISP tower signal to share Internet to local wireless and wired network.
