55IN LCD 3840X2160 TOUCH MNTR 40PT 350NIT HDMI WEBOS 4.1
SKU: 8JT055VPN: 55TC3CG-H
55IN LCD 3840X2160 TOUCH MNTR 40PT 350NIT HDMI WEBOS 4.1
Key Features
- IPS Display with wide viewing angles
- Multi Touch Screen (Up to 40 points)
- webOS 4.1 Smart Signage Platform
- Anti-shatter Glass & Conformal Coating
- SuperSign CMS, Control/Control+
Request a Quote on This Product
Adding to inquiry lets you bundle multiple products into a single quote request.
Overview
Engage your Audience
The 55TC3CG-H offers high touch performance and great color with vivid details that can seen at virtually any angle.
High Touch Performance | Precise Touch Response
The screen accurately recognizes extremely small touch points and instantly shows a response. This means that SIs can compose GUI icons in a variety of sizes on the 55TC3CG-H and users can fully enjoy their touch experience with no lagging.
Multi Touch with No Dead Zones
Capable of recognizing up to 40 point-touches at once, the screen provides multiple users a smooth and natural sense of touch. Unlike infrared touch screens, the 55TC3CG-H accurately detects touch points even at the corners or edges of the display. This allows a variety of touch-based customer services to be provided throughout the entire screen.
Excellent Picture Quality | Beautiful Color, Wide View
LG IPS panel features a wide viewing angle to deliver clear content regardless of where meeting participants are seated.
Vivid Details with Ultra HD
Ultra High Definition resolution allows users to view details even when zooming in on the display, with four times higher definition than Full HD.
Product Reliability | Fewer Scratches & Shatter Proof
Touch screens in public spaces can be scratched in heavy use or even abuse situations. The 55TC3CG-H has an advanced tempered screen coating to minimize scratches. In addition, its anti-shatter glass is designed to minimize harm to the user, even in the event the product being subject to abuse.
Conformal Coating
The product can be often unavoidably exposed to dust and water during maintenance. Conformal coating on the circuit board virtually eliminates such circumstances by protecting it against dust, iron powder, humidity, etc.
Easy Content Management | Embedded Group Manager
The embedded content management system allows you to edit and play content, schedule a playlist and even group and control signage via remote control, without need for a separate PC. This makes content management much easier and user-friendly.
Multi Screen Mode
PBP (Picture-By-Picture) and PIP (Picture-In-Picture) enables up to two divided split screens in landscape or portrait display format enabling users to more flexibly allocate space for each content source.
Tech Specs
| Depth | 1.8" |
|---|---|
| Width | 50.3" |
| Height | 29.6" |
| DVI-D In | No |
| Features | Picture in Picture |
| Speakers | No |
| Bluetooth | No |
| Brand Name | LG |
| Brightness | 350 Nit |
| USB Type-C | No |
| Bezel Color | Black |
| Color Depth | 10-bit |
Show all 84 specsShow fewer
| Color Gamut | 72% NTSC |
|---|---|
| Energy Star | Yes |
| Orientation | Landscape/Portrait |
| Touchscreen | Yes |
| Aspect Ratio | 16:9 |
| Embedded CMS | Local Contents Scheduling |
| HDCP Version | 1.4/2.2 |
| Manufacturer | LG Electronics |
| Product Name | 55TC3CG-H Digital Signage Display |
| Product Type | Digital Signage Display |
| Wireless LAN | No |
| Audio Line In | No |
| Input Voltage | 120 V AC |
| Product Model | 55TC3CG-H |
| RS-232C Input | Yes |
| Response Time | 9 ms |
| TAA Compliant | No |
| Accuracy Touch | 78.7 mil |
| Audio Line Out | Yes |
| DisplayPort In | Yes |
| RS-232C Output | Yes |
| Infrared Output | No |
| Network (RJ-45) | No |
| Operation Hours | 24 Hours/7 Days |
| Maximum LED Life | 5.7 Year |
| Operating System | webOS 4.1 |
| Package Contents | <li>Power Cord 1.55 M*1</li><li> USB Cable (Type A-Type B) 1.8 M*1</li><li> HDMI Cable 3 M*1</li><li> User Manual</li><li> QSG</li><li> Remote Controller (include battery 2ea)</li><li> RS232C cable (3.5mm)</li><li> IR Receiver </li><li> Magnet Sheet (3ea)</li> |
| Panel Technology | In-plane Switching (IPS) Technology |
| Bezel Width (Top) | 1.32" |
| Power Consumption | 145 W |
| Bezel Width (Left) | 1.31" |
| Display Resolution | 3840 x 2160 |
| DisplayPort Output | Yes |
| Multi-touch Screen | Yes |
| Bezel Width (Right) | 1.31" |
| Compatible Software | Mobile CMS |
| VESA Mount Standard | 300 x 300 |
| Backlight Technology | Edge LED |
| Bezel Width (Bottom) | 1.50" |
| Viewable Screen Size | 55" |
| Weight (Approximate) | 78 lb |
| Front Glass Thickness | 0.13" |
| Native Contrast Ratio | 1,000:1 |
| Number of HDMI Inputs | 2 |
| Standard Refresh Rate | 60 Hz |
| Additional Information | <li>Surface Treatment (Hard Coating) : No</li> <li>Surface Treatment (Anti Glare) : No</li> <li>Anti-Reflective : No</li> <li>Transparency : No</li> <li>Internal Memory : 8 GB (System 4 GB + Available 3.6 GB) (eMMC)</li> <li>BTU Heat Generation (Typ.) : 358 BTU</li> <li>Handle : No</li> <li>Direct Sunlight : No</li> <li>Response Time (PC Win10, Education Mode) : ≤100 ms</li> <li>Operating System Support : Win 8.1 / 10, Linux (Kernel v3.0 above)</li> <li>Power Loop Out : No</li> <li>HDMI Out : No</li> <li>Power Loop In : No</li> <li>RGB In : No</li> <li>Power In (DC From External PWR Box) : No</li> <li>Anti-Reflective Coating : No</li> <li>Heater : No</li> <li>Anti-Reflective Film : No</li> <li>Heat Dissipation : No</li> <li>Degree of Protection : No</li> <li>OPS Power Built-in : No</li> <li>OPS Compatible : No</li> <li>UL Certification : No</li> <li>DisplayPort In : Yes (x1) HDCP 2.2/1.3</li> <li>Displayport Out : Yes (x1), input HDMI 1 / 2 / DP / OPS</li> <li>External Speaker Out (3.5 mm) : Yes (6 ohm)</li> <li>IR In (3.5 mm) : Yes</li> <li>RS-232C In (3.5 mm 4-pin) : Yes (x1)</li> <li>RS-232C In (D-sub 9-pin) : No</li> <li>RS-232C Out (3.5 mm) : Yes (x1)</li> <li>Touch USB : Yes (x1) USB 2.0</li> <li>Power Type : Built-in Power</li> <li>Local Key Operation: Yes</li> <li>Touch Interface : USB 2.0</li> |
| Dynamic Contrast Ratio | 500,000:1 |
| Vertical Viewing Angle | 178° |
| Content Synchronization | RS-232C |
| Maximum Heat Generation | 522.3 kJ |
| Number of USB 2.0 Ports | 2 |
| Power Consumption (DPM) | Less Than 0.5W |
| Environmentally Friendly | Yes |
| Horizontal Viewing Angle | 178° |
| Manufacturer Part Number | 55TC3CG-H |
| Number of Audio Line Out | 1 |
| Certifications & Standards | <li>FCC: EMC Class A</li> <li>CE Marking (Regulatory): Yes</li> |
| Maximum Operating Humidity | 80% |
| Minimum Operating Humidity | 10% |
| Off-Mode Power Consumption | 500 mW |
| Touch Object Size Diameter | 0.24" |
| Environmental Certification | ErP |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Manufacturer Website Address | https://solutions.lg.com/us |
| Maximum Operating Temperature | 104°F (40°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Number of DisplayPort Outputs | 1 |
| Protection Glass Transmission | 83% |
| Number of Network (RJ-45) Ports | 1 |
| On Screen Display (OSD) Languages | Swedish |
| Number of Simultaneous Touchpoints | 40 |
| Image Sticking Minimization (ISM) Method | Yes |
