ADVANTECH (B+B SMARTWORX)

4GE + 2SFP PORT MANAGED ETHERN SWITCH WIDE TEMP

SKU: 8DB453VPN: EKI-7706G-2FI-AE

4GE + 2SFP PORT MANAGED ETHERN SWITCH WIDE TEMP

Key Features

  • 4 Gigabit Ethernet ports + 2 SFP ports
  • SFP socket for easy and flexible fiber expansion
  • Redundancy: X-Ring Pro (ultra high-speed recovery time
  • IXM function enables fast deployment
  • Security: 802.1x (Port-based, MD5/TLS/TTLS/PEAP encryption), RADIUS
  • Management: SNMP v1/v2c/v3, WEB, Telnet, standard MIB, private MIB
  • -40 ~ 85 °C wide-range operating temperature (EKI-7706G-2FI)
  • Dual 12~48 VDC power input and 1 relay output
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

EKI-7706G-2F/2FI supports 4 Gigabit Ethernet ports and 2 SFP ports. It provides abundant ports to connect many devices and it is embedded with Advantech’s IXM function, which benefits users with fast deployment and can dramatically save engineers time and costs. The EKI-7706G series also supports NMS to help IT managers with networking maintenance and failure prevention. Finally, the EKI-7706G series is equipped with X-Ring Pro which can achieve ultra-high-speed recovery times of less than 20 ms to ensure network stability.

Tech Specs

4GE + 2SFP PORT MANAGED ETHERN SWITCH WIDE TEMP specifications
Depth3.3"
Width1.7"
Height4.7"
ModularYes
Brand NameAdvantech
ManageableYes
Form FactorWall Mountable
ManufacturerAdvantech Co., Ltd
Product Name4GE+2G SFP Managed Ethernet Switch
Product TypeEthernet Switch
Input Voltage48 V DC
Product ModelEKI-7706G-2FI
Show all 32 specs
Product FamilyEKI-7700
Product SeriesEKI-7700
Product MaterialMetal
Power Consumption5.28 W
Network Technology10/100/1000Base-TX
Ethernet TechnologyGigabit Ethernet
Expansion Slot TypeSFP
Number of SFP Slots2
Media Type SupportedOptical Fiber
Networking StandardsIEEE 802.1p
Weight (Approximate)15.87 oz
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
Environmentally FriendlyYes
Manufacturer Part NumberEKI-7706G-2FI-AE
Maximum Data Transfer Rate128 MB/s
Port/Expansion Slot Details4 x Gigabit Ethernet Network
Manufacturer Website Addresshttp://www.advantech.com
Total Number of Network Ports4
Total Number of Expansion Slots2
Redundant Power Supply SupportedYes
