2PT USB TO SERIAL RS232 ADAPTER USB TO RS232 DB9 CONVERTER CABLE

SKU: KF6404VPN: ICUSB2322F

In Stock

$77.89$58.63

Actual pricing depends on volume, configuration, and current promotions. Reach out and we'll put together a real quote — often below this number.

Key Features

CUSTOMIZABLE SOLUTION: This USB serial hub features an FTDI chipset, making it highly customizable and compatible, and the ideal solution for any setup; Integrated 2500Vrms Optical Isolation Circuits
MULTI-USE FUNCTIONALITY: This versatile USB to serial RS232 adapter is perfect for a range of applications, from digital signage to connecting point-of-sale systems and barcode scanners
COMPACT DESIGN: Designed with a small form factor, this serial RS232 converter is USB powered and requires no bulky power adapters or an outlet; Wall mountable design
EASY INSTALLATION: This serial adapter ensures easy installation and operation with COM port retention that provides robust serial connectivity for legacy devices
TECH SPECS: 6 feet (1.8 meters); FTDI FT2232D Chipset; Max Baud Rate: 921.6 Kbps; 128 Bytes FIFO; None/Odd/Even/Mark/Space Parity Modes; 7 or 8 Data Bits; 1 or 2 Stop bits; TAA Compliant

Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

The ICUSB2322F 2-Port USB to Serial RS232 Adapter Cable with FTDI chipset and COM Retention converts an available USB 1.1 or 2.0 port into 2 RS232 serial DB9 ports to connect, monitor and control your serial devices. This compact adapter features COM retention, allowing the same COM port values to automatically be re-assigned to the port if the cable is disconnected and re-connected to the host computer, or if the system is rebooted. Unlike most USB-serial adapters, this one uses the FTDI chipset, which supports additional customization, advanced features, and compatibility not necessarily offered by other solutions. This USB-serial adapter is compatible with a broad list of Operating Systems, including Windows®, Windows CE, Mac OS and Linux, making this product the perfect solution for integrating into mixed environments. Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Tech Specs

2PT USB TO SERIAL RS232 ADAPTER USB TO RS232 DB9 CONVERTER CABLE specifications
Brand Name	StarTech.com
Cable Length	6 ft
Color Family	Black
Manufacturer	StarTech.com
Product Name	2 Port FTDI USB to Serial RS232 Adapter Cable with COM Retention
Product Type	Data Transfer Adapter
Product Color	Black
Number of Ways	2-way
Package Contents	<ul> <li>2 Port FTDI USB to Serial RS232 Adapter Cable with COM Retention</li> <li>1x Driver CD</li> <li>1x Instruction Manual</li> <li>1x Wall Mounting Kit</li> </ul>
Product Material	Plastic
Country of Origin	Taiwan
Packaged Quantity	1 Each

Show all 27 specs

Weight (Approximate)	5.50 oz
Additional Information	<p><b>OS Compatibility:</b></p><li>Windows® 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64), 2000, CE(4.2+)</li><li>Windows Server® 2012, 2008 R2, 2003</li><li>Mac OS® 10.x (tested up to 10.10), 9.x</li><li>Linux</li>
Environmental Compliance	Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Environmentally Friendly	Yes
Manufacturer Part Number	ICUSB2322F
Certifications & Standards	<ul><li>FCC</li><li>CE</li></ul>
Connector Type on First End	USB 2.0 Type A - Male
Environmental Certification	EU RoHS
Connector Type on Second End	DB-9 RS-232 Serial - Male
Manufacturer Website Address	http://www.startech.com
Connector Gender on First End	Male
Connector Gender on Second End	Male
Connector on First End Details	1 x 4-pin USB 2.0 Type A - Male
Operating System Compatibility	Windows Server 2022
Connector on Second End Details	2 x 9-pin DB-9 RS-232 Serial - Male
