STARTECH.COM

2 PORT PCIE NETWORK CARD LAN GIGABIT ETHERNET NIC ADAPTER RJ45

SKU: YB0872VPN: ST1000SPEXD4

2 PORT PCIE NETWORK CARD LAN GIGABIT ETHERNET NIC ADAPTER RJ45

Key Features

  • Two 10/100/1000Mbps compatible RJ-45 Ethernet ports
  • Up to 9K Jumbo Frame support
  • Compatible with PCI Express Base Specification 2.0 (backward compatible with 1.0a/1.1)
  • Fully Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, and supports IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding and IEEE 802.3x Full Duplex Flow Control
  • Supports Microsoft NDIS5 Checksum Offload (IP, TCP, UDP) and Large send Offload
  • Wake-on-LAN / Remote Wake-up support
  • Configured with standard profile bracket, low profile/half-height bracket included
  • Supports Pair Swap / Polarity / Skew Correction
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

Add dual Gigabit Ethernet ports to a client, server or workstation through a PCI Express slot. The ST1000SPEXD4 PCI Express Dual-Port Gigabit Network Card lets you add two gigabit Ethernet ports to a client, server or workstation through a single PCIe slot. Each port provides 10/100/1000 Mbps capable Ethernet and is fully compatible with IEEE 802.3/u/ab standards. Suitable for any standard PCI Express-enabled system, the 2-port Ethernet card supports full-duplex flow control for maximum data transfer speeds of up to 2000 Mbps - an ideal 2-port NIC for setting up dual-homed, or multi-homed host configurations providing added security to corporate networks. The dual-port server adapter is compliant with the PCIe 2.0 standard and features support for Jumbo Frames and 802.1q VLAN tagging as well as Wake on LAN (WoL). The adapter includes an optional low-profile / half-height bracket that can be used for installation into a standard or small form-factor computer chassis. Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Tech Specs

2 PORT PCIE NETWORK CARD LAN GIGABIT ETHERNET NIC ADAPTER RJ45 specifications
Depth3.6"
Width0.7"
Height4.7"
Brand NameStarTech.com
Form FactorPlug-in Card
ManufacturerStarTech.com
Product NameDual Port Gigabit PCI Express Server Network Adapter Card - PCIe NIC
Product TypeGigabit Ethernet Card
Host InterfacePCI Express x1
Device SupportedServer
Package Contents<ul><li>Dual Port Gigabit PCI Express Server Network Adapter Card - PCIe NIC</li><li>1 x Low Profile Bracket</li><li>1 x Driver CD</li><li>1 x Instruction Manual</li></ul>
Country of OriginChina
Show all 25 specs
Packaged Quantity1 Each
Network Technology10/100/1000Base-T
System Requirements<ul> <li>Windows® 2000, XP, Vista, 7, 8, 8.1, 10</li> <li>Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016, 2019</li> <li>Mac OS 10.4 to 10.9</li> <li>Linux 2.4.x to 4.11.x LTS Versions only </li> </ul>
Media Type SupportedTwisted Pair
Weight (Approximate)1.90 oz
Total Number of Ports2
Environmental ComplianceWaste Electrical and Electronic Equipment Directive (WEEE)
Environmentally FriendlyYes
Manufacturer Part NumberST1000SPEXD4
Maximum Data Transfer Rate1.95 Gbit/s
Environmental CertificationEU RoHS
Manufacturer Website Addresshttp://www.startech.com
Number of Network (RJ-45) Ports2
