STARTECH.COM

2-PORT DUAL-MONITOR DP KVM DUAL-VIEW VIDEO MATRIX 4K 60HZ

SKU: SN1693VPN: P2ADD121D-KVM-SWITCH

2-PORT DUAL-MONITOR DP KVM DUAL-VIEW VIDEO MATRIX 4K 60HZ

Key Features

  • VIDEO MATRIX KVM SWITCH: Functions as a KM-only or full KVM switch: view one screen from each computer and switch keyboard, mouse, and USB audio between them (KM only), or control both displays and peripherals from a single PC (KVM)
  • MULTIPLE SWITCHING OPTIONS: Easy to switch KVM ports using the front-facing pushbutton, hotkeys, or the included remote selector cable, with an audible buzzer providing confirmation; LEDs provide quick visual port selection status
  • UNIVERSAL COMPATIBILITY: TAA-Compliant KVM Switch provides BIOS/UEFI control and works with any operating system including Windows, macOS, and Linux; No software required; Compatible with all hardware platforms such as Intel, AMD, and Apple Silicon
  • DURABLE DESIGN: Steel housing helps prevent Electro-Magnetic Interference (EMI) enhancing stability and reliability of the KVM; Sturdy construction makes it ideal for installation in a variety of environments; 8kV Air/6kV Contact ESD protection
  • OUR ADVANTAGE: Included connectivity tools for IT Pro's and IT help-desk support teams with USB Event Monitoring for logging USB device connections with timestamps, and Windows Layout to restore windows locations upon switching hosts
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

The Video Matrix KVM Switch allows you to view one display from each connected computer and switch the keyboard, mouse, and audio device between the selected displays using hotkeys. You can also switch all connected peripherals and both monitors like a standard KVM.

Universal Compatibility

The TAA-Compliant KVM Switch provides BIOS/UEFI control and works with any operating system, including Windows, macOS, and Linux. No software is required, and it is compatible with all hardware platforms such as Intel, AMD, and Apple Silicon.

Customizable Switching

Switching KVM ports is easy with the front-facing push button, hotkeys, or the included remote selector cable. An audible buzzer provides confirmation, and LEDs offer quick visual port selection status.

Reliable Performance

The durable design features a steel housing that helps prevent Electro-Magnetic Interference (EMI), enhancing the stability and reliability of the KVM. Its sturdy construction makes it ideal for installation in a variety of environments, and it offers 8kV Air/6kV Contact ESD protection.

USB Audio

Eliminate the need to connect 3.5mm cables from the computers to the KVM by using this KVM switch's built-in USB audio device, which provides 3.5mm audio jacks for both microphone and speakers. This setup simplifies your workspace by integrating audio management directly into the KVM switch.

Enhance Productivity and Device Management with the StarTech.com Connectivity Tools Application

Developed to improve performance and security, StarTech.com Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software suite includes:

  • Advanced Windows Layout Utility: Setup and save custom windows layouts.
  • USB Event Monitoring Utility: Track and log connected USB devices.

For more information and to download the StarTech.com Connectivity Tools application, please visit: www.startech.com/connectivity-tools

Tech Specs

2-PORT DUAL-MONITOR DP KVM DUAL-VIEW VIDEO MATRIX 4K 60HZ specifications
USBYes
Width4.1"
Height1"
Length8.70"
USB 2.0Yes
FeaturesLED Indicator
Brand NameStarTech.com
DisplayPortYes
Graphic Mode4K
ManufacturerStarTech.com
Product NameKVM Switchbox
Product TypeKVM Switchbox
Show all 31 specs
USB StandardUSB 2.0
Input Current1 A
TAA CompliantYes
Power Plug TypeType M
Package Contents<ul><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>KVM Switch</li><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>1x Remote Selector Cable</li><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>1x Universal Power Adapter (NA/EU/UK/ANZ)</li><li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>1x Quick-Start Guide</li></ul><p><br></p>
Country of OriginTaiwan
Packaged Quantity1
Input Voltage Range100 - 240 AC
Number of USB Ports6
Weight (Approximate)1.38 lb
Number of DisplayPorts6
Connectivity TechnologyWired
Environmental ComplianceWaste Electrical and Electronic Equipment Directive (WEEE)
Manufacturer Part NumberP2ADD121D-KVM-SWITCH
Maximum Video Resolution3840 x 2160
Manufacturer Website Addresshttp://www.startech.com
Maximum Operating Temperature104°F (40°C)
Minimum Operating Temperature32°F (0°C)
Number of Computers Supported2
