STARTECH.COM

2.5 TO 3.5 HARD DRIVE ADAPTER HOT SWAP SATA SAS HDD SSD CONVERTER

SKU: LJ6815VPN: 25SATSAS35

2.5 TO 3.5 HARD DRIVE ADAPTER HOT SWAP SATA SAS HDD SSD CONVERTER

Key Features

  • Trayless design: hard drives are not mounted into separate trays/enclosures
  • Supports 2.5" form factor hard drives (HDD) and solid state drives (SSD) up to 15mm in height
  • Power indicator LED
  • Lightweight plastic construction with air vents
  • Plug and Play and hot swap compatible
  • Support for SATA revision I/II/III (1.5/3.0/6.0 Gbps)
  • Support for SAS revision I/II (3.0/6.0 Gbps)
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

The 25SATSAS35 2.5-inch SATA/SAS to 3.5-inch SATA Hard Drive Converter converts a 2.5-inch SATA or SAS hard drive (HDD) or solid state drive (SSD) into a 3.5-inch form factor SATA Hard Drive. The converter provides a versatile solution for 2.5-inch drive installations, enabling you to install a 2.5-inch SATA/SAS drive in a 3.5-inch bay, drive drawer caddy/tray, or into a 3.5-inch drive enclosure. To maximize performance and utilize the full speed potential of your SATA III hard drives, this HDD Backplane supports SATA III for transfer speeds up to 6 Gbps when paired with compatible controller. Suitable for drives with a height of up to 15mm, virtually any 2.5-inch SATA or SAS hard drive can be made to look and function like a 3.5-inch hard drive. The drive converter includes mounting holes along the side and base, allowing you to mount the drive if needed, into a compatible system. The Drive Converter features a trayless design for simple drive installation and removal, and is constructed of durable, yet lightweight plastics, with ventilation openings to aid air flow and help keep hard drives running cooler. Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Tech Specs

2.5 TO 3.5 HARD DRIVE ADAPTER HOT SWAP SATA SAS HDD SSD CONVERTER specifications
Depth5.7"
Width3.9"
Height1"
Brand NameStarTech.com
Cooling FanNo
Form FactorInternal
Color FamilyBlack
ManufacturerStarTech.com
Product Name2.5in SATA/SAS SSD/HDD to 3.5in SATA Hard Drive Converter
Product TypeDrive Bay Adapter
Wireless LANNo
Product ColorBlack
Show all 33 specs
Host InterfaceSerial ATA/600
Drive InterfaceSATA/600
Package Contents<ul> <li>2.5in SATA/SAS SSD/HDD to 3.5in SATA Hard Drive Converter</li> <li>10 x Screws (6 Round, 4 Flat)</li> <li></li> </ul>
Product MaterialPlastic
Country of OriginChina
Packaged Quantity1 Each
Number of 2.5" Bays1
Weight (Approximate)4.80 oz
Additional Information<ul><li>A trayless design and support for 15mm drives enables quick and easy install/removal of drives, including newer high capacity drives</li><li>Uses standard 3.5" form factor mounting points, along with 3 mounting points on the sides, for compatibility with some OEM branded systems, such as Dell</li><li>Can be mounted into a 3.5" front bay as a 2.5" HDD Mobile Rack or treated as a regular 3.5" hard drive</li></ul>
Environmental ComplianceRestriction of Hazardous Substances (RoHS) 2
Environmentally FriendlyYes
Manufacturer Part Number25SATSAS35
Certifications & Standards<ul><li>FCC</li><li>CE</li></ul>
Compatible Drive Bay Width3.5"
Environmental CertificationEU RoHS
Manufacturer Website Addresshttp://www.startech.com
Number of Total Expansion Bays1
Number of Hard Drives InstalledNo
Number of Hard Drives Supported1
Number of Solid State Drive InstalledNo
Number of Solid State Drive Supported1
