STARTECH.COM

1U 16 PORT USB VGA KVM SWITCH USB VGA RACKMOUNT KVM OSD

SKU: CN6224VPN: SV1631DUSBU

1U 16 PORT USB VGA KVM SWITCH USB VGA RACKMOUNT KVM OSD

Key Features

  • OS Independent No drivers or software required
  • Auto-scan function automatically selects computer sequentially
  • Cascade configuration expands system capability
  • Front panel push-button and Hotkey switching allow easy computer access
  • Identifies and selects computers by the names assigned using the OSD
  • USB console connections
  • OSD security allows each PC to be password protected
  • Plug-and-play system configuration
  • Supported Wide Screen Resolutions: 1920x1200, 1920x1080, 1680x1050, 1400x1050, 1440x900, 1360x768
  • Supported 4 : 3 Resolutions: 1920x1440, 1600x1200, 1280x1024, 1024x768
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

The SV1631DUSBU 16 Port 1U Rack Mountable USB KVM Switch with OSD lets you control 16 USB computers from a single console (USB keyboard, USB mouse, VGA monitor). Convenient push-button and hot-key controls provide quick, reliable switching between connected computers while manual and auto-scan switching modes and an On Screen Display (OSD) offer additional control options. Designed to ensure maximum space efficiency, the USB KVM switch features a slim 1U design that fits neatly into a server equipment rack/cabinet with the included brackets, and can be cascaded with multiple KVM switches to deliver control of up to 136 computers from this single switch. Rear cable connections help to eliminate cable tangles and minimize workspace disruption. This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support. The SV1631DUSBU onlyworks with specific 2-in-1 VGA and USB cables (soldseparately), a list ofStarTech.com approved cables are below: 6ft Ultra Thin USB VGA 2-in-1 KVM Cable 6ft Ultra Thin USB VGA 2-in-1 KVM Cable 10 ft Ultra Thin USB VGA 2-in-1 KVM Cable 15ft Ultra Thin USB VGA 2-in-1 KVM Cable

Tech Specs

1U 16 PORT USB VGA KVM SWITCH USB VGA RACKMOUNT KVM OSD specifications
USBYes
Depth7.1"
Width21.3"
Height1.8"
Brand NameStarTech.com
Form FactorDesktop
Rack Height1U
Color FamilyBlack
ManufacturerStarTech.com
Product Name16 Port 1U Rack Mount USB KVM Switch with OSD
Product TypeKVM Switchbox
Input Voltage230 V AC
Show all 27 specs
Product ColorBlack
Product ModelSV1631DUSBU
TAA CompliantYes
Package Contents<ul> <li>16 Port 1U Rack Mount USB KVM Switch with OSD</li> <li>2 x Mounting Brackets</li> <li>1 x Bag of Screws</li> <li>1 x Pack Rubber Feet</li> <li>1 x Power Adapter</li> <li>1 x User Manual</li> </ul>
Country of OriginTaiwan
Packaged Quantity1 Each
Input Voltage Range110V AC to 240V AC
Number of USB Ports2
Weight (Approximate)6.83 lb
Daisy Chain SupportedYes
Environmentally FriendlyYes
Manufacturer Part NumberSV1631DUSBU
Maximum Video Resolution1920 x 1440
Manufacturer Website Addresshttp://www.startech.com
Number of Computers Supported16
