OMNITRON SYSTEMS
16 PORT T1/E1 MUX W/ENET MGT 1G SC SM SF 15/13NM 40KM -40-60C 2XDC
SKU: DV5824VPN: 2431-2-44W
16 PORT T1/E1 MUX W/ENET MGT 1G SC SM SF 15/13NM 40KM -40-60C 2XDC
Request a Quote on This Product
Adding to inquiry lets you bundle multiple products into a single quote request.
Overview
The iConverter T1/E1 MUX/M multiplexes up to sixteen T1 or E1 circuits and one 10/100/1000 Ethernet service onto a fiber optic transport link, and features remotely managed testing and configuration capabilities.
The iConverter T1/E1 MUX/M operates in a back-to-back configuration, and can be used in applications such as multiple T1/E1 extension, mobile backhaul and building-to-building PBX connectivity.
The T1/E1 copper interfaces are available in 4, 8, 12 or 16 RJ-48 port configurations for balanced T1/E1 applications. Optional adapter cables are available to convert each RJ-48 interface to a BNC interface for unbalanced E1 transport applications.
Additional hot-swappable 4-Port T1/E1 MUX modules can be installed to increase system capacity up to 16 T1/E1 ports maximum per 1U (1.75 inch) chassis.
Tech Specs
| Depth | 9" |
|---|---|
| Width | 17.2" |
| Height | 1.8" |
| Brand Name | Omnitron Systems |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Manufacturer | Omnitron Systems |
| Product Line | iConverter |
| Product Name | iConverter 2431-2-44W T1/E1 Multiplexer |
| Product Type | Data Multiplexer |
| Product Model | 2431-2-44W |
| Management Port | Yes |
Show all 24 specsShow fewer
| Package Contents | <ul><li>iConverter 2431-2-44W T1/E1 Multiplexer</li><li>4 x 4-Port T1/E1 MUX Module</li><li>2 x VDC Power Supply</li></ul> |
|---|---|
| Country of Origin | United States |
| Number of SC Ports | 1 |
| Media Type Supported | Optical Fiber |
| Weight (Approximate) | 7.50 lb |
| Connectivity Technology | Wired |
| Manufacturer Part Number | 2431-2-44W |
| Maximum Data Transfer Rate | 1 Gbit/s |
| Manufacturer Website Address | http://www.omnitron-systems.com |
| Network Technology Supported | 1000Base-X |
| Number of Network (RJ-45) Ports | 1 |
| Total Number of Expansion Slots | 4 |
