120V 30A 4X5-15R 2XL5-20R MICROPOD MAINTENANCE BYPASS.

SKU: 632074VPN: MP2-130P

In Stock

$456.54

Actual pricing depends on volume, configuration, and current promotions. Reach out and we'll put together a real quote — often below this number.

Key Features

Manual switchover from UPS to utility power
Allows continuous operation for connected equipment during UPS maintenance or replacement
Installs with plug-and-play ease
Operates with any brand of UPS, 3kVA or smaller

Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

Liebert® MicroPOD allows manual uninterruptible power supply (UPS) bypass, powering the connected load with utility power during UPS maintenance or replacement, to ensure continuous operation of critical computer equipment. The unit has two modes of operation, UPS mode (UPS available) and utility mode (maintenance bypass). The rackmount unit can support any brand of UPS, 3kVA or smaller; in 50Hz or 60Hz models.

Tech Specs

120V 30A 4X5-15R 2XL5-20R MICROPOD MAINTENANCE BYPASS. specifications
Depth	3.5"
Width	17"
Height	3.5"
Current	24 A
Brand Name	Vertiv Liebert
Form Factor	Rack-mountable
Rack Height	2U
Receptacles	2 x NEMA L5-20R
Manufacturer	Vertiv
Product Line	MicroPOD
Product Name	MicroPOD MP2-130P Bypass Switch
Product Type	Bypass Switch

Show all 24 specs

Compatibility	Liebert Micro-UPS Systems
Input Voltage	120 V AC
Product Model	MP2-130P
Output Voltage	120 V AC
Protection Type	Signal
Package Contents	<ul> <li>MicroPOD MP2-130P Bypass Switch</li> <li>Brackets for Rack Mounting</li> </ul>
Country of Origin	China
Plug/Connector Type	NEMA L5-30P
Additional Information	<ul><li>The POD is designed to operate as a maintenance bypass system in the following modes</li></ul><ul><li>Normal - The UPS is continuously supplied available utility power by the POD. The UPS output power is returned to the POD and distributed to the critical AC load through the POD output receptacles</li><li>Maintenance Bypass - The bypass switch allows a transfer of the critical AC load from the UPS inverter to the utility source; to allow for service to or replacement of the UPS, without interrupting the load</li></ul><ul><li>Bypass Switch: The bypass switch is capable of switching up to 20 or 30 amps, based on the model of the POD. The switch is a break before make type, with a maximum transfer time of 6ms</li><li>Connection to UPS Input: L5-30R</li><li>Connection to UPS Output & cord length: L5-30P on attached 6 foot cord</li></ul>
Manufacturer Part Number	MP2-130P
Certifications & Standards	<ul> <li>UL</li> <li>cUL</li> </ul>
Manufacturer Website Address	http://www.vertiv.com/
