STARTECH.COM

1000FT BLUE CAT5E CABLE PLENUM BULK SOLID WIRE ETHERNET RJ45 SPOOL

SKU: RZ1213VPN: WIR5ECMPBL

1000FT BLUE CAT5E CABLE PLENUM BULK SOLID WIRE ETHERNET RJ45 SPOOL

Key Features

  • CAT5e ETHERNET CABLE: 1000 ft. Solid UTP Cat5e cable is optimized for enterprise 1000 Mbps networks; 350 MHz frequency range enhances throughput capacity; Supports Power over Ethernet (PoE)
  • QUALITY CONSTRUCTION: High-quality copper conductors enable a precise fit to minimize wear and signal loss; 24 AWG solid copper supporting a diverse range of Ethernet applications
  • SAFETY AND RELIABILITY: Carefully constructed and tested, to keep Near End Crosstalk (NEXT) well within acceptable limits; Reliable Ethernet connections in applications requiring plenum rated Cat5e Cable
  • APPLICATIONS: Ideal for installations (air plenums, ducts, walls, conduits, ceilings, etc.) where air circulates in buildings and CMP Plenum products are required
  • SPECIFICATIONS: CAT5e; Blue; 1000 foot; 10/100/1000Mbps; 350 MHz; PoE; UTP; Solid; 24AWG Pure Bare Copper; CMP/FT6 Plenum; TAA
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

The WIR5ECMPBL Cat5e Plenum Bulk Cable (1000 ft) meets or exceeds all Cat 5e specifications to ensure reliable Ethernet network connections, and features a foot-marked jacket that enables you to measure your cable runs to your exact installation requirements. Also, the blue PVC jacket enables you to color code your drops as needed for a more organized installation. Constructed of only top quality materials, the WIR5ECMPBL delivers reliable performance and is backed by our Lifetime Warranty. Plenum Rated This Category 5e cable has been tested for CMP (FT6) plenum-ratings, and is ideal for installation in air plenums, ducts, walls, conduit, ceilings, etc. where CMP fire rating is required. 100% Copper - a better value StarTech.com Cat5e cables are manufactured using high-quality copper conductors. While many cable manufacturers offer a "cheaper" cable, based on a copper-coated aluminum core, we make no compromises on quality to ensure you receive top value and performance for your network cable investment. 24 AWG Wire This Cat 5e cable is constructed with 24 gauge copper wire, to support a broad range of Ethernet applications such as Power over Ethernet (PoE). Because we use a high quality copper wire, our cables easily sustain the power required for Power over Ethernet applications, whereas the inferior quality offered by copper-coated aluminum cables may be subject to insufficient power delivery, heat buildup, equipment damage and potentially, fire. More from the Manufacturer

Tech Specs

1000FT BLUE CAT5E CABLE PLENUM BULK SOLID WIRE ETHERNET RJ45 SPOOL specifications
PackingReel Box
FeaturesWear Resistant
ConductorCopper
ShieldingNo
Brand NameStarTech.com
Cable TypeCategory 5e
Jacket TypeFT6
Cable Length1000 ft
Color FamilyBlue
ManufacturerStarTech.com
Package TypeBulk
Product Name1000 ft Roll of Blue Plenum CMP Cat5e Solid UTP Bulk Cable
Show all 39 specs
Product TypeNetwork Cable
Product ColorBlue
TAA CompliantYes
WEEE Statementhttps://media.startech.com/cms/pdfs/wir5ecmpbl_weee.pdf
Jacket MaterialPolyvinyl Chloride (PVC)
Device SupportedNetwork Device
Material Details<p> aluminum - cable</p>
Product MaterialBare Copper
Country of OriginTaiwan
Packaged Quantity1 Each
Data Transfer Rate1 Gbit/s
REACH free of SVHCYes
American Wire Gauge24 AWG
Weight (Approximate)23.59 lb
REACH Declaration URLhttps://media.startech.com/cms/pdfs/wir5ecmpbl_rohs.pdf
EU RoHS Declaration URLhttps://media.startech.com/cms/pdfs/wir5ecmpbl_rohs.pdf
Environmental ComplianceRestriction of Hazardous Substances (RoHS) 2
Environmentally FriendlyYes
Manufacturer Part NumberWIR5ECMPBL
Certifications & StandardsUL
Connector Type on First EndBare Wire
Environmental CertificationEU RoHS
Connector Type on Second EndBare Wire
Manufacturer Website Addresshttp://www.startech.com
Connector on First End DetailsBare Wire
Connector on Second End DetailsBare Wire
End of Life Manual AvailabilityYes
