STARTECH.COM

1 PORT PCIE NETWORK CARD LAN GIGABIT ETHERNET NIC ADAPTER INTEL

SKU: 1N0234VPN: ST1000SPEXI

1 PORT PCIE NETWORK CARD LAN GIGABIT ETHERNET NIC ADAPTER INTEL

Key Features

  • Add a 10/100/1000 RJ-45 Ethernet port to a client, server or desktop through one PCIe slot
  • Intel I210-AT chipset
  • PXE network boot
  • Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
  • Auto MDIX support
  • Autonegotiation support
  • Wake-on-LAN support
  • Up to 9K jumbo frame support
  • IEEE802.3az Energy Efficient Ethernet (EEE)
  • Supports IEEE 802.1Q VLAN tagging
Request a Quote on This Product

Adding to inquiry lets you bundle multiple products into a single quote request.

Overview

Boost the performance and capabilities of your server or desktop computer by adding a Gigabit Ethernet port through a PCI Express slot. This GbE (Gigabit Ethernet) network card makes it easy to create a highperformance, cost-effective networking solution.The performance and reliability you demand in network connectivityThis Gigabit Ethernet network card utilizes the Intel® I210-AT chipset, designed to deliver the power, performance and enhanced capabilities you need for dependable network connections to your server or computer. Compliant with IEEE 802.3/u/ab standards, the network card provides an effective upgrade or replacement network port with maximum throughput up to 1000Mbps in each direction (2000 Mbps total) - up to ten times faster than 10/100 Ethernet. The I210 chipset provides many advanced features to support load-balancing the flow of network traffic, to enhance throughput and provide greater data reliability. It also supports Audio-Video Bridging (AVB) to enable tightly controlled media stream synchronization, buffering and resource reservation.A versatile and cost-effective solutionCompatible with a broad range of operating systems, this versatile PCIe Gigabit NIC is ideal for many business applications requiring upgrades to servers or workstations, adding feature-rich Gigabit networking. It's a cost-effective way to upgrade your server or computer from a 10/100 Ethernet port to a Gigabit Ethernet port, or add an Ethernet port to take advantage of advanced features such as VLAN tagging, Jumbo Frames, Wake-On LAN and Auto MDIX.Easy installationWith a dual-profile design, the PCI Express network card installs easily into a wide range of computer/server chassis, regardless of form factor. The card comes equipped with a full-sized bracket, and includes a low profile/half-height installation bracket that you can use as needed. The ST1000SPEXI is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Tech Specs

1 PORT PCIE NETWORK CARD LAN GIGABIT ETHERNET NIC ADAPTER INTEL specifications
Depth2.7"
Width2.6"
Height0.7"
Brand NameStarTech.com
Form FactorPlug-in Card
Color FamilyBlack
ManufacturerStarTech.com
Product Name1-Port Gigabit Ethernet Network Card - PCI Express, Intel I210 NIC
Product TypeGigabit Ethernet Card
Chipset ModelI210-AT
Product ColorBlack
Host InterfacePCI Express x4
Show all 30 specs
Device SupportedComputer
Package Contents<ul> <li>1-Port Gigabit Ethernet Network Card - PCI Express, Intel I210 NIC</li> <li>1 x Low Profile Bracket</li> <li>1 x Instruction Manual</li> </ul>
Country of OriginChina
Packaged Quantity1 Each
Network Technology10/100/1000Base-T
Platform SupportedLinux
System Requirements<ul> <li>Windows® 7, 8, 8.1, 10</li> <li>Windows Server® 2008 R2, 2012 R2, 2016, 2019 </li> <li>Linux 2.4.x to 4.11.x LTS versions only </li> </ul>
Chipset ManufacturerIntel
Media Type SupportedTwisted Pair
Weight (Approximate)1.30 oz
Total Number of Ports1
Environmental ComplianceRestriction of Hazardous Substances (RoHS) 2
Environmentally FriendlyYes
Manufacturer Part NumberST1000SPEXI
Maximum Data Transfer Rate1.95 Gbit/s
Environmental CertificationEU RoHS
Manufacturer Website Addresshttp://www.startech.com
Number of Network (RJ-45) Ports1
